Addi-Data APCI-3000 Technical Description page 46

Standardsoftware
Functionality
b_ADDIDATA_Read1AnalogInput
Available parameters:
- Interrupt:
- Conversion time unit:
- Convert time:
b_ADDIDATA_ReadMoreAnalogInputs
Available parameters:
- Interrupt:
- Conversion time unit:
- Convert time: 10 to 65535 for µs
b_ADDIDATA_ConvertDigitalToRealAnalogValue
b_ADDIDATA_ConvertMoreDigitalToRealAnalogValues
b_ADDIDATA_InitAnalogInputSCANAcquisition
Available parameters:
- Conversion time unit:
- Convert time:
- Scan mode:
- Delay mode:
- Delay timing:
b_ADDIDATA_StartAnalogInputSCAN
b_ADDIDATA_GetAnalogInputSCANStatus
b_ADDIDATA_ConvertDigitalToRealAnalogValueSCAN
b_ADDIDATA_StopAnalogInputSCAN
b_ADDIDATA_CloseAnalogInputSCAN
b_ADDIDATA_EnableDisableAnalogInputHardwareTrigger
Available parameters:
- Level:
- Action:
b_ADDIDATA_GetAnalogInputHardwareTriggerStatus
b_ADDIDATA_GetAnalogInputSoftwareTriggerInformation
46
Enabled/disabled
1 to 65535 for ms
High/Low
SCAN
One shot
Single cycle
x cycles
Return:
- Can be used for SCAN
- One shot trigger mode available
- Single cycle trigger mode available
- X cycle trigger mode available
Function name
Enabled/disabled
µs/ms
10 to 65535 for µs
1 to 65535 for ms
µs/ms
µs/ms
10 to 65535 for µs
1 to 65535 for ms
Single/X cycles/ continuous
Not used/Mode1/Mode2
µs/ms
APCI-3xxx
