10. PROBLEM SOLVING

PROBLEM
The WINTEX 1000 does not start.
The probe does not rotate.
The soil cannot be squeezed out of the
probe.
The ATV is being lifted when the probe
goes into the ground.
The ejector cannot pass through the
probe tube.
The probe does not stop spinning.
The drilling head will go down, but would not
come up.
The drilling head hits the soil box.
CAUSE
1) The fuse is blown.
2) The emergency stop is activated.
3) Does not activate all switches.
4) A switch is defect.
5) There is a lack of power supply.
1) The fuse is blown.
2) The chain is broken.
1) The ejector tip is worn.
2) The probe is choked up with soil.
3) The probe is bent.
4) The ejector is bent.
1) The oil pressure is too high.
1) The ejector is stuck.
2) The chain is dislocated.
3) The soil sampler's movement is
blocked by soil.
1) The sensor is not adjusted correctly.
2) The sensor not adjusted correctly.
3) A wire fell out of the sensor in the
drilling head or the middle sensor.
4) The wires which are going to the
computer are disconnected.
1) The sensor not adjusted correctly or
the sensor is broken.
2) The hydraulic pressure on the
Honda motor is too low.
3) Bad connection to the Honda
Motor.
4) A nut fell off between the hydraulic
cylinder and slide for the soil box.
5) Broken computer.
6) The wires are disconnected from
the computer (Q2 or Q3).
7) The battery of the ATV is weak
and is not sending the full 12 volts.
Wintex Agro, Vilhelmsborgvej 15, DK-7700 Thisted
+45 97990800, contact@wintexagro.com, www.wintexagro.com
POSSIBLE SOLUTIONS
1) Put in a new fuse.
2) Deactivate the emergency stop.
3) See manual point 1.
4) Change the switch.
5) Charge the battery.
1) Put in a new fuse.
2) Replace the chain.
1) Change the ejector tip.
2) Clean the probe for soil.
3) Exchange the probe (manual point 3).
4) Adjust the ejector (manual point 8)
1) Reduce the oil pressure.
1) Adjust the ejector (manual point 8).
2) Adjust and tighten the chain (manual point 6).
3) Clean the soil sampler.
1) Move the middle sensor in the tower closer to
the drilling head or replace it.
2) Move the sensor in the drilling head closer to
the funnel or replace it.
3) Re-connect the wire.
4) Re-connect the wires (I4 or I6).
1) Move the bottom sensor closer to the drilling
head, or replace the bottom sensor.
2) Adjust the pressure.
3) Check the connection to the Honda motor.
4) Re-place the nut.
5) Install a new computer.
6) Re-connect the wires.
7) Recharge or change the battery.
1) Adjust the bucket bearing.
