8. ADJUSTMENT OF EJECTOR

9. MAINTENANCE

Important: After the first eight hours of operation, screws, bolts and nuts must be tightened.
Daily:
- Lubricate chain with oil spray. Avoid the oil to get in touch with the aluminium rails.
- Lubricate the hinges of the soil box.
- Clean the ejector.
- Clean the chain for the rotation of the probe (is easily carried out with compressed air).
- Clean the parts where soil can be accumulated.
Weekly:
- Check and tighten vital parts.
- Check and if necessary change the ejector tip.
- Check and if necessary change the probe.
- Check the oil level of the hydraulics.
When adjusting the ejector make sure to stop the probe approximately 10 cm from the start
position. Turn off the WINTEX 1000, and activate the emergency stop.
Loosen the six Allen screws (three at the top and three below). Then loosen the nut for the probe.
Adjust the ejector so that it is placed in the middle of the hole of the probe.
Tighten the screws and the nut again, and the probe will move back into start position. If necessary
adjust the ejector by slightly bending it when it is free from the probe tube.
