Advanced tank measurement
methods
Direct level measurement modes
Measuring mode
Level only
1
1
2
Level + temperature
3
1
2
3
48

Application packages

The device software provides the following tank measurement methods:
• Direct level measurement →  48
• Hybrid tank measurement system (HTMS) →  49
• Hydrostatic tank shell correction (HyTD) →  50
• Thermal tank shell correction (CTSh) →  50
Direct level measurement
If no advanced tank measurement methods have been selected, level and temperature are measured
directly.
Installation example
2
NMS8x
To inventory management system
1
2
NMS8x
To inventory management system
Temperature transmitter (point or average)
Measured variables
Level
A0026820
• Level
• Temperature (point or average)
A0026829
Proservo NMS81
Calculated variables
None
None
