Proservo NMS81
Endress+Hauser
23
Mounting position of relief valve and pressure gauge
1
Pressure gauge
2
Relief valve
Cleaning nozzle and gas purging nozzle
A cleaning nozzle used for washing inside housing is especially recommended for F&B or alcohol
applications.
A gas purging nozzle used for purging gas inside the housing is especially recommended for a
nitrogen blanket for petrochemical or chemical applications.
24
Holes for cleaning nozzle and gas purging nozzle
1
Cleaning nozzle
2
Gas purging nozzle
1
2
1
2
A0029103
A0028883
53
