Dimensions

Weight

40

Mechanical construction

414 (16.8)
73 (2.87)
218 (8.58)
The thickness of the flange (22 mm (0.87 in)) shows the specification of the 10K 150A RF
aluminium flange JIS B2220.
30 kg (66.1 lb)
314 (12.36)
218 (8.58)
Proservo NMS81
227.5 (8.96)
48 (1.89)
A0026821
Endress+Hauser
