WARNING!
- Carefully read the manual before the installation or use.
- This equipment is to be installed by qualified personnel, complying to current standards, to avoid damages or safety hazards.
- Before any service work on the device, remove all the voltages from measuring and supply inputs and short-circuit the CT input terminals.
- The manufacturer cannot be held responsible for electrical safety in case of improper use of the equipment.
- Products illustrated herein are subject to alteration and changes without prior notice. Technical data and descriptions in the documentation are accurate, to the best of our knowledge, but no liabilities for errors,
omissions or contingencies arising there from are accepted.
- A circuit breaker must be included in the electrical installation of the building. It must be installed close by the equipment and within easy reach of the operator. It must be marked as the disconnecting device of the
equipment: IEC /EN 61010-1 § 6.11.3.1.
- Clean the device with a soft dry cloth; do not use abrasive products, liquid detergents or solvents.
INDEX
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyboard functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front LED indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First power-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Password access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display page navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table of display pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Harmonic analysis page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Waveform page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Expandability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Communication channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inputs, outputs, internal variables, counters, analog inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limit thresholds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote-controlled variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command of DCTL thyristor modules via RS485 bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IR programming port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter setting through PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter setting (setup) from front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output functions table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input functions table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm property table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Commands menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Measurement table for limit thresholds and analog outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Terminal arrangement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mechanical dimensions and panel cutout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical carachteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB
AUTOMATIC POWER FACTOR CONTROLLER
Instructions manual
DCRG8F
G
B
Page
2
2
2
2
2
3
3
3
4
4
5
6
6
7
7
7
8
8
8
8
9
10
10
11
14
14
19
19
19
20
20
21
23
24
24
24
25
1
Advertisement
Chapters
Table of Contents
Related Manuals for LOVATO ELECTRIC DCRG8F
Summary of Contents for LOVATO ELECTRIC DCRG8F
-
Page 1: Table Of Contents
AUTOMATIC POWER FACTOR CONTROLLER Instructions manual LOVATO ELECTRIC S.P.A. 24020 GORLE (BERGAMO) ITALIA VIA DON E. MAZZA, 12 TEL. 035 4282111 E-mail info@ ovato lectric.com www. ovato lectric.com DCRG8F WARNING! – Carefully read the manual before the installation or use. -
Page 2: Introduction
The DCRG8F automatic power factor controller has been designed incorporating the state of the art in the functions required for dynamic power factor correction applications. Made with a dedicated housing of extremely compact dimensions, DCRG8F combines a modern front panel design with practical fitting and the possibility of expansion at the back, where modules of the EXP series can be housed. The LCD graphic display permits a clear and intuitive user interface. -
Page 3: Operating Modes
OPERATING MODES The correctly selected mode is displayed in reverse at the centre of the home page. There are three possible operating modes, listed below: TEST Mode – When the controller is brand new and has never been programmed, it automatically enters in TEST mode that allows the installer to manually activate the individual outputs, so the correct wiring of the panel can be checked. -
Page 4: Display Page Navigation
FRONT BUTTON LOCK The front buttons can be locked to prevent involuntary access to the pages of DCRG8F. To enable the button lock, go to the main page and then, holding down the ◄ button, press the L button three times then the M button twice. -
Page 5: Harmonic Analysis Page
PAGINE ESEMPIO Energy meters 1 - Key ► switches between Total/Partial indications Event log 1 - Event description 2 - Event time stamp 3 - Event number / total Expansion status Real time clock System 1 - Level of revision for: information Software Hardware... -
Page 6: Waveform Page
– The graph is automatically updated about every second. EXPANDABILITY – Thanks to the expansion bus, DCRG8F can be expanded with additional modules of the EXP series. – It is possible to connect a maximum of 4 EXP… modules at the same time. -
Page 7: Additional Resources
– The two channels can communicate at the same time. – By activating the Gateway function, it is possible to have a DCRG8F equipped with an Ethernet port and a RS485 port which works as a “bridge” towards the other devices provided with the RS485 port only, and so obtain a saving (one Ethernet access point only). -
Page 8: Limit Thresholds
– These are variables which status can be modified by the user through the communication protocol and that can be used in combination with outputs. – Example: using a remote variable (REMx) as a source for an output (OUTx), it will be possible to freely energise or de-energise one relay through the supervision software. This would allow the use of DCRG8F outputs to control loads, e.g. -
Page 9: Ir Programming Port
In addition is necessary to set a different step number on every DCTL thyristor module, which must be equal to the step number set on the DRG8F regulator (e.g.: if I have configured on DCRG8F the step 3 as “Static-... -
Page 10: Parameter Setting Through Pc
PARAMETER SETTING (SETUP) WITH PC – Xpress configuration and remote control software can be used to transfer parameters (previously set) from the DCRG8F to a PC hard disk and vice versa. – Parameter transfer from a PC to the DCRG8F may be partial, i.e. only the parameters of specified menus will be transferred. -
Page 11: Parameter Tables
– If the user does not press any key for more than 2 minutes, the system leaves the setup automatically and goes back to normal viewing without saving the changes done on parameters. – Remember that, solely for the setup data that can be edited using the buttons, a backup copy can be made in the DCRG8F’s EEPROM. This data can be restored, when necessary, in the work memory. The data backup copy and restore commands can be found in the commands menu. - Page 12 M02 - GENERAL Default Range P02.01 CT primary OFF/1-30000 P02.02 CT secondary 1 / 5 P02.03 Type of plant installation Three-ph Three-phase Single phase P02.04 Current reading phase L1 / L2 / L3 L1-L2-L3 P02.05 CT polarity Aut - Dir - Rev P02.06 Voltage reading phase L1-L2...
- Page 13 Output type NOR - REV Note: This menu is divided into 24 sections, which refer to 24 possible digital outputs OUT01…OUT24 that can be managed by DCRG8F, of which OUT01..OUT08 on the basic device and OUT09…OUT24 on any expansion modules.
-
Page 14: Output Functions Table
OUTPUT FUNCTION TABLE – The following table shows all the functions that can be attributed to the OUTn programmable digital outputs. – Each output can be configured so it has a normal or reverse (NOR or REV) function. – Some functions require another numeric parameter, defined in the channel number x specified by parameter P04.n.02. –... - Page 15 M16 – COMMUNICATION (COMn, n=1…2) Default Range P16.n.01 Node serial address 01-255 P16.n.02 Serial port speed 9600 1200 2400 4800 9600 19200 38400 57600 115200 P16.n.03 Data format 8 bit – n 8 bit - no parity (n) 8 bit, odd 8 bit, even 7 bit, odd 7 bit, even...
- Page 16 Note: This menu is divided into 8 sections for counters CNT1...8. P21.n.01 – Signal that increments the count (on rising edge). It may be energised by the DCRG8F (ON), the exceeding of a threshold (LIMx), the activation of an external input (INPx), etc.
- Page 17 Note: This menu is divided into 6 sections, for the generation of energy consumption pulse variables PUL1…PUL6. P24.n.01 – Defines which energy meter must generate the pulse, from the 6 possible meters managed by DCRG8F. kWh+ = imported active energy; kWh- = exported active energy; kvarh+ = inductive reactive energy; kvarh- = capacitive reactive energy;...
- Page 18 M25 – USER ALARMS (UAn, n=1…8) Default Range P25.n.01 Alarm source OFF-INPx-OUTx- LIMx-REMx P25.n.02 Channel number source x OFF / 1-99 P25.n.03 Text (text – 20 char) Note: This menu is divided into 8 sections for user alarms UA1...UA8. P25.n.01 – Defines the digital input or internal variable that generates the user alarm when it is activated. P25.n.02 –...
-
Page 19: Alarms
– Alarms can be cleared by pressing – If the alarm cannot be cleared, the condition that generated the alarm must still be solved. – If one or more alarms occur, the behaviour of the DCRG8F will depend on the active alarm property setting. ALARM DESCRIPTION... -
Page 20: Alarm Property Table
ALARM PROPERTY TABLE CODE DEFAULT ALARM PROPERTIES COMMANDS MENU – The commands menu allows executing some occasional operations, such as measurement reset, counter clearing, alarm reset, etc. – If the advanced access password was entered, the control menu can also be used to perform automatic operations useful for configuring the controller. –... -
Page 21: Measurement Table For Limit Thresholds And Analog Outputs
MEASUREMENT TABLE FOR LIMIT THRESHOLDS AND ANALOG OUTPUTS – The following table lists all measurements that can be associated with the limit thresholds (menu M20) and analog outputs (menu M23). – The codes selected in the parameters P20.n.01 and P23.n.02 correspond to the measurements below. –... - Page 22 EVENTS LIST CODE SYSTEM CODE ACCESS E0000 ACTIVATION E0700 SETUP MENU ACCESS E0001 SWITCHING OFF E0703 CLOCK SET.ACCESS E0002 SYSTEM RESET COMMANDS ALARMS E0800 C01 RES .PART. ENERG. E0200 ALARM START E0801 C02 RES. CNT E0201 ALARM END E0802 C03 RESET LIMITS E0202 ALARM RESET E0803...
-
Page 23: Wiring Diagrams
– With this configuration is possible to monitor from the display of DCRG8F controller the status and the measures of each DCTL thyristor module. – Note. The EXP1012 mounted on DCRG8F controller is dedicated for the command of DCTL thyristor modules. If necessary to connect the DCRG8F controller to a supervision system (e.g. a PC) is necessary to add another communication expansion module, at choice between the codes compatible with DCRG8F (in the wiring diagram above is shown as example another RS485 module EXP1012). -
Page 24: Terminal Arrangement
INSTALLATION – DCRG8F is designed for flush-mount installation. With proper mounting, it guarantees IP65 front protection degree. – Insert the controller into the panel cutout, making sure the gasket is properly positioned between the panel surface and the controller front frame. -
Page 25: Technical Carachteristics
TECHNICAL CHARACTERISTICS Supply Insulation Rated voltage Us ‚ 100 - 415V Rated insulation voltage Ui 600V 110 - 250V Rated impulse withstand voltage Uimp 9.5kV Operating voltage range 90 - 456V Power frequency withstand voltage 5.2kV 93.5 - 300V Ambient conditions Frequency 45 - 66Hz Operating temperature... - Page 26 REGOLATORE AUTOMATICO DEL FATTORE DI POTENZA Manuale operativo LOVATO ELECTRIC S.P.A. 24020 GORLE (BERGAMO) ITALIA VIA DON E. MAZZA, 12 TEL. 035 4282111 E-mail info@ ovato lectric.com www. ovato lectric.com DCRG8F ATTENZIONE! – Leggere attentamente il manuale prima dell’utilizzo e l’installazione.
-
Page 27: Introduzione
Il regolatore automatico del fattore di potenza DCRG8F è stato progettato incorporando lo stato dell’arte delle funzioni richieste per le applicazioni di rifasamento dinamico. Realizzato con un contenitore dedicato, di dimensioni estremamente compatte, DCRG8F unisce il moderno design del frontale alla praticità di montaggio e alla possibilità di espansione sul retro, dove è possibile alloggiare moduli della serie EXP. Il display grafico LCD consente una interfaccia utente chiara ed intuitiva. -
Page 28: Modi Operativi
MODI OPERATIVI Il modo operativo selezionato correntemente è visualizzato in negativo al centro della pagina principale. Esistono tre possibili modi operativi, elencati di seguito: Modo TEST – Quando l’apparecchio é nuovo di fabbrica e non è mai stato programmato, entra automaticamente nel modo TEST che consente all’installatore di attivare manualmente le singole uscite, in modo da poter verificare la correttezza del cablaggio del quadro. -
Page 29: Navigazione Fra Le Pagine Del Display
BLOCCO TASTI FRONTALI E possibile inserire il blocco dei tasti frontali per evitare accessi involari alle pagine di DCRG8F. Per abilitare il blocco dei tasti bisogna posizionarsi sulla pagina principale e successivamente, tendendo premuto il tasto ◄, premere tre volte il tasto L e successivamente per 2 volte il tasto M. Sul display tramite una finestra pop-up verrà notificato l'avvenuto blocco dei tasti. Eseguire la stessa procedura per lo sblocco. -
Page 30: Pagina Analisi Armonica
PAGINE ESEMPIO Contatori 1 - Con il tasto ► si commuta di energia l’indicazione Totali / Parziali Lista eventi 1 - Descrizione evento 2 - Data-ora evento 3 - Numero evento / totali Stato espansioni Orologio datario Informazioni 1 - Livello di revisione per: di sistema Software Hardware... -
Page 31: Pagina Forme D'onda
PAGINA FORME D’ONDA – Questa pagina rappresenta graficamente la forma d’onda dei segnali di tensione e di corrente letti da DCRG8F. – E’ possibile vedere una fase per volta, selezionandola con i tasti ◄ e ►. – La scala verticale (ampiezza) è regolata automaticamente in modo da visualizzare al meglio possibile il segnale. -
Page 32: Risorse Aggiuntive
– I canali di comunicazione possono funzionare contemporaneamente. – Attivando la funzione Gateway, è possibile avere una DCRG8F equipaggiata con una porta Ethernet ed una porta RS485 che fa da “ponte” verso altri DCRG dotati della sola porta RS485, in modo da ottenere un risparmio (1 solo punto di accesso Ethernet). -
Page 33: Soglie Limite
COMANDO MODULI A TIRISITORI SERIE DCTL VIA BUS RS485 Il regolatore DCRG8F, se utilizzato in abbinamento a moduli a tiristori Lovato serie DCTL, può comandare i moduli a tiristori tramite bus seriale RS485. Rispetto al comando tramite uscite statiche, questa modalità, oltre a realizzare un cablaggio semplice e lineare su bus, consente di monitorare lo stato e le misure elettriche di ogni modulo a tiristori DCTL (es. -
Page 34: Porta Di Programmazione Ir
La porta COM numero n del regolatore DCRG8F è dedicata per il comando dei moduli a tiristori DCTL via bus RS485. In aggiunta è necessario impostare su ogni modulo a tiristori DCTL un nodo seriale differente, che deve corrispondere al numero dello step impostato sul regolatore DCRG8F (esempio: se configuro sulla DCRG8F lo step 3 come “Statico-485”, il corrispondente DCTL deve avere P01.04=3). -
Page 35: Impostazione Parametri Da Pc
IMPOSTAZIONE PARAMETRI DA PC – Mediante il software di configurazione e controllo remoto Xpress è possibile effettuare il trasferimento dei parametri (precedentemente impostati) da DCRG8F al disco del PC e viceversa. – Il trasferimento dei parametri da PC a DCRG8F può essere parziale, cioè solo i parametri dei menù specificati. -
Page 36: Tabella Dei Parametri
– Se non vengono premuti tasti per 2 minuti consecutivi, il menu setup viene abbandonato automaticamente e il sistema torna alla visualizzazione normale senza salvare i parametri. – Si rammenta che per i soli dati di setup modificabili da tastiera, è possibile fare una copia di sicurezza (backup) nella memoria eeprom di DCRG8F. Questi stessi dati all’occorrenza possono essere ripristinati (restore) nella memoria di lavoro. - Page 37 M02 - GENERALE Default Range P02.01 Primario TA OFF/1-30000 P02.02 Secondario TA 1 / 5 P02.03 Tipologia impianto Trifase Trifase / Monofase P02.04 Fase lettura correnti L1 / L2 / L3 / L1-L2-L3 P02.05 Verso collegamento TA Aut - Dir - Inv P02.06 Fase lettura tensioni L1-L2...
- Page 38 Uscita normale / inversa NOR - REV Nota: Questo menu è diviso in 24 sezioni, riferite alle 24 possibili uscite digitali OUT01…OUT24 gestibili da DCRG8F, di cui OUT01..OUT08 sull’apparecchio base e OUT09…OUT24 sugli eventuali moduli di espansione. P04.n.01 – Scelta della funzione della uscita selezionata (vedi tabella funzioni uscite programmabili a pagina 14).
-
Page 39: Tabella Funzioni Uscite
TABELLA FUNZIONI USCITE – La tabella seguente riporta tutte le funzioni che possono essere associate alle uscite digitali programmabili OUTn. – Ciascuna uscita può essere poi impostato in modo da avere funzione normale o invertita (NOR o REV). – Alcuni funzioni necessitano di un ulteriore parametro numerico, definito con il numero canale x specificato dal parametro P04.n.02. –... - Page 40 M16 – COMUNICAZIONE (COMn, n=1…2) Default Range P16.n.01 Indirizzo seriale nodo 01-255 P16.n.02 Velocità seriale 9600 1200 2400 4800 9600 19200 38400 57600 115200 P16.n.03 Formato dati 8 bit – n 8 bit - n (no parità) 8 bit, dispari 8 bit, pari 7 bit, dispari 7 bit, pari...
- Page 41 P21.n.01 – Segnale che provoca l’incremento del conteggio (sul fronte di salita). Può essere la messa in tensione di DCRG8F (ON), il superamento di una soglia (LIMx), l’attivazione di un ingresso esterno (INPx), ecc. P21.n.02 – Numero canale riferito al parametro precedente.
- Page 42 Nota: Questo menu è diviso in 6 sezioni, per la generazione delle variabili impulso sul consumo energia PUL1…PUL6. P24.n.01 – Definisce da quale contatore di energia deve essere generato l’impulso, fra i 6 possibili contatori gestiti da DCRG8F. kWh+ = energia attiva importata; kWh- = energia attiva esportata; kvarh+ = energia reattiva induttiva; kvarh- = energia reattiva capacitiva; kVAh = energia apparente totale.
- Page 43 M25 – ALLARMI UTENTE (UAn, n=1…8) Default Range P25.n.01 Sorgente allarme OFF-INPx-OUTx- LIMx-REMx P25.n.02 Numero canale sorgente (x) OFF / 1-99 P25.n.03 Testo allarme utente UAx (testo – 20 char) Nota: Questo menu è diviso in 8 sezioni, per la definizione degli allarmi utente UA1…UA8. P25.n.01 –...
-
Page 44: Allarmi
– Il reset degli allarmi si può effettuare premendo il tasto – Se l’allarme non si resetta, significa che persiste la causa che lo ha provocato. – In seguito al verificarsi di uno o più allarmi, DCRG8F ha un comportamento basato sull’impostazione delle proprietà degli allarmi attivi. DESCRIZIONE DEGLI ALLARMI COD. -
Page 45: Tabella Allarmi
TABELLA ALLARMI COD. PROPRIETA’ ALLARMI DI DEFAULT MENU COMANDI – Il menu comandi permette di eseguire operazioni saltuarie quali azzeramenti di misure, contatori, allarmi, ecc. – Se è stata immessa la password per accesso avanzato, allora tramite il menu comandi è anche possibile effettuare delle operazioni automatiche utili ai fini della configurazione del regolatore. –... -
Page 46: Tabella Misure Per Soglie Limite E Uscite Analogiche
TABELLA MISURE PER SOGLIE LIMITI E USCITE ANALOGICHE – La tabella seguente riporta tutte le misure che possono essere associate ai limiti (LIMx, menu M20) e alle uscite analogiche (AOUx, menu M23). – Le sigle selezionate nei parametri P20.n.01 e P23.n.02 corrispondono alle misure riportate sotto. –... - Page 47 LISTA EVENTI CODICE SISTEMA CODICE ACCESSO E0000 ACCENSIONE E0700 ACCESSO MENU SETUP E0001 SPEGNIMENTO E0703 ACCESSO IMP.OROLOGIO E0002 RESET SISTEMA COMANDI ALLARMI E0800 C01 AZZ. ENERG. PARZ E0200 INIZIO ALLARME E0801 C02 AZZ. CNT E0201 FINE ALLARME E0802 C03 AZZ. LIMITI E0202 RESET ALLARMI E0803...
-
Page 48: Schemi Di Collegamento
– Con questa configurazione è possibile monitorare dal display del regolatore DCR8GF lo stato e misure di ogni modulo a tiristori DCTL. – Nota. Il modulo EXP1012 montato sul regolatore DCRG8F è dedicato al comando dei moduli a tiristori DCTL. Se necessario connettere il regolatore DCRG8F ad un sistema di supervisione (es. un PC) è... -
Page 49: Disposizione Morsetti
INSTALLAZIONE – DCRG8F è destinato al montaggio da incasso. Con il corretto montaggio garantisce una protezione frontale IP65. – Inserire il regolatore nella foratura del pannello, accertandosi che la guarnizione sia posizionata correttamente fra la superfice del pannello e la cornice del regolatore. -
Page 50: Caratteristiche Tecniche
CARATTERISTICHE TECNICHE Alimentazione Isolamento Tensione nominale Us ‚ 100 - 415V Tensione nominale d’isolamento Ui 600V 110 - 250V Tensione nom. di tenuta a impulso Uimp 9,5kV Limiti di funzionamento 90 - 456V Tensione di tenuta a frequenza d’esercizio 5,2kV 93,5 - 300V Condizioni ambientali Frequenza...
