MecPower Tecway Power storm Manual page 11

2) Put the seat part and chassis part together again and fix with six M8 * 35 screw,
connect the connector and the seat air supply pipe joint.
M8*35平 内 六 角 机 丝 M8*35 screw
M8*35平 内 六 角 机 丝
M8*35 screw
M 8*35平 内 六 角 机 丝
M8*35 screw
3) use the M4 * 20 big screw to fix the left and right sides of the yellow ring blister and
white blister.
Yellow ring blister
黄色环形吸塑
M4*20大扁自攻
M4*20 screw
大轮奶白吸塑
White wheel blister
M4*20 screw
M4*20大扁自攻
机 箱 与 座 椅 组 件 连 线 接 头 ,
Connector for computer part and seat
座 椅 供 气 管
part, air pipe for seat part
11
