S1 Electric Trolley
Instruction Manual
EN
REGISTERONLINE
www.motocaddy.com/warranty
Visit www.motocaddy.com/instructions for other Motocaddy instructions including translations

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Motocaddy S1

  • Page 1 S1 Electric Trolley Instruction Manual REGISTERONLINE www.motocaddy.com/warranty Visit www.motocaddy.com/instructions for other Motocaddy instructions including translations...
  • Page 2: Table Of Contents

    Contents Locating your Serial Number / Information about DHC ........................3 Safety Cut-out / Safe use of your Trolley ............................4 Caring for your Trolley ..................................5 Battery Care & Advice / Battery Care Tips ............................6 Charging your Lithium Battery .................................7 Lithium Battery Hibernation / Battery Management System ......................8 Attaching the Wheels ..................................9 Unfolding &...
  • Page 3: Locating Your Serial Number / Information About Dhc

    Locating your Serial Number / Information about DHC Locating your Serial Number The serial number for your Motocaddy trolley is located on the underside of the battery tray. This number is required when registering your warranty online and should be kept handy for future use.
  • Page 4: Safety Cut-Out / Safe Use Of Your Trolley

    Safety Cut-out This Motocaddy trolley is fitted with a timed safety cut-out feature. Once started the trolley will automatically cut power to the motor after ten minutes to prevent any possible damage to the trolley. Pressing the on/off button will reset your trolley.
  • Page 5: Caring For Your Trolley

    Never use a pressure washer to clean your trolley. To prevent water damage, wipe down with a damp cloth • Avoid using high pressure air hoses near moving components Your Motocaddy trolley is designed to require very little maintenance. We do however recommend giving your trolley regular checks to ensure: •...
  • Page 6: Battery Care & Advice / Battery Care Tips

    All batteries must be charged as soon as possible after each use. Leaving batteries discharged for long periods of time will affect the battery life. Please ensure that only batteries supplied by Motocaddy are charged with Motocaddy chargers. Cyclic battery chargers are designed specifically in accordance with the battery manufacturer’s requirements. The Lithium battery charger MUST NOT be used to charge any other battery and is designed for use with Motocaddy Lithium batteries only.
  • Page 7: Charging Your Lithium Battery

    Charging your Lithium Battery Charging your Lithium Battery Unplug the Lithium battery from the trolley. This should always be performed before folding the trolley to avoid damage to the battery and/or trolley Plug the charger into your mains supply Attach the battery cable to the charger matching the black and white (or blue) connections When the charging LED indicator has turned green, the battery is fully charged and ready to be used RED - Battery Charging GREEN - Battery fully charged and ready to be disconnected...
  • Page 8: Lithium Battery Hibernation / Battery Management System

    BMS may switch-off the battery. A full battery charge will rectify this problem. Motocaddy golf trolleys are designed to work with the BMS system installed in the Lithium batteries and the voltage meter is also synchronised to work in conjunction with the battery. If for any reason the voltage on the battery falls below the low battery warning on the trolley, then the BMS may disable the battery to protect it.
  • Page 9: Attaching The Wheels

    Attaching the Wheels Attaching the Wheels There is a left and a right wheel and it is important that you don’t put them on the wrong way round, otherwise the trolley will not move. There is an ‘L’ and ‘R’ on the inside of the wheel on the central hub.
  • Page 10: Unfolding & Folding Your Trolley

    Unfolding your Trolley This Motocaddy trolley is fitted with the QUIKFOLD system, allowing you to fold and unfold your trolley quicker than ever before. Unfolding your Trolley Press and hold the upper QUIKFOLD release button (fig. 1) Lift the handle and release the button (fig. 2) Unfold the upper frame section fully (fig.
  • Page 11 Folding your Trolley Folding your Trolley Make sure your battery is unplugged Ensure that the upper bag support has been folded up to avoid damage to the frame whilst folding Press and hold the lower QUIKFOLD release button (fig. 1) Lower the main frame completely, releasing the button at any point (fig.
  • Page 12: Using & Adjusting The Bag Supports

    Fig 1 Using the Lower Bag Supports This Motocaddy trolley is fitted with the EASILOCK™ bag attachment system. If you are using an EASILOCK™ compatible golf bag please follow these simple instructions: Remove the two pre-fitted lower bag straps by depressing the rear button and sliding (fig. 3) Match up the indicating line on the golf bag with the line on the lower bag support Lower the bag until the pins lock in position.
  • Page 13 Adjusting the Bag Supports Adjusting the Bag Supports Fig 1 The bag support straps are manufactured from elasticated material to allow your golf bag to be held tightly in place. The strap should be adjusted to be reasonably tight around the golf bag: Unclip the elasticated straps from the housing by pulling outwards in the direction shown (fig.
  • Page 14: Equipment Overview

    Equipment Overview Equipment Overview LCD Digital Display Speed Setting (see pg 15) Advanced Battery Meter (see pg 15) Speed Controller & On/Off Button (see pg 15) Upper Bag Support QUIKFOLD Upper Release Button QUIKFOLD Lower Release Button Rear Wheels Rear Wheel Release Button 10.
  • Page 15: Starting, Stopping & Changing Speed

    Starting, Stopping & Changing Speed Starting, Stopping & Changing Speed The S1 is very simple to control. There is one main button that is used to start and stop the trolley, whilst also controlling the speed, which can be adjusted while the trolley is stationary or in motion.
  • Page 16: Battery Meter / Battery Setting

    Battery Meter / Battery Setting Battery Meter The S1 includes an on-screen battery meter which provides an indication of remaining battery capacity. The number of illuminated bars will decrease as the battery capacity reduces. | | | | | The trolley is designed to protect your battery from being fully discharged, should your battery capacity drop too low the trolley will cut the power to the motor.
  • Page 17: Introduction To Dhc / Using The Dhc Parking Brake

    Whenever you are looking to move the trolley, even if just to reposition it ready to use, always put it on a low speed setting to make it easier to steer. Fig 1 - S1 DHC Using the DHC Parking Brake DHC models are fitted with an electronic parking brake.
  • Page 18: Adjusting The Front Wheel Alignment

    Adjusting the Front Wheel Alignment Adjusting the Front Wheel Alignment if your trolley is veering In the unlikely event that your trolley is not tracking in a straight line, the alignment of the front wheel can be adjusted to rectify the fault. This problem can be caused by a number of factors including a slightly loose bag support or an unevenly packed golf bag.
  • Page 19: Declaration Of Conformity

    Declaration of Conformity Model: S1/S1 DHC/S3 PRO/S3 PRO DHC/ S5 CONNECT/S5 CONNECT DHC/S7 REMOTE/ M1/M1 DHC/M3 PRO/M3 PRO DHC/ M5 CONNECT/M5 CONNECT DHC/M5 GPS/ M5 GPS DHC/C-TECH Tuesday January 01, 2019 John Helas Managing Director Page 19...
  • Page 20 +44 (0)1279 712 370 e: info@motocaddy.com w: www.motocaddy.com We are dedicated to protecting the environment and encourage the recycling of Motocaddy products through a free collection and disposal service. To find out more or to locate your nearest Motocaddy recycling point, please contact us through our website.
