Model #8000X Outside Safety Ladder

PARTS LIST

Qty. Description
2- Handrails
2- Stringers / Legs
4- Upper Treads
1- Bottom Tread
2- Shields
2- Tread Connector
(RH & LH)
1- Platform (wedges attached)
see Step #2.
Note: Assemble this ladder before assembling the Confer-Step-1X.
If you have already assembled the Confer-Step-1X it will be
necessary to remove the handrails (see step #10).
Check building codes/permitting. Consult your local Building Department before installation of your pool
and equipment. Pool/equipment installation must comply with the codes of the authority having jurisdiction
and may require permits (e.g., building, plumbing, electrical, zoning, etc.).
Use for intended purpose only
• Use only as swimming pool ladder.
• This ladder is designed and manufactured for a specific pool wall height and/or deck of the pool -
check product specification and the height of your pool.
Check that you have all required parts. Check the contents of the carton with the Parts list for this step
system. All parts and hardware are required. If any parts are missing, DO NOT attempt to assemble or
install the steps. Instead, call Toll Free U.S. - 800-635-3213 or visit our web site at www.conferladders.
com for assistance.
Select an appropriate location - The step system must be located on a solid base.
Follow all instructions
• For stable, correct assembly and installation, all instructions must be followed completely and in the
sequence shown.
• Follow the manufacturer's recommendations for the safe use of all hand tools and equipment used
during installation.
Cordless drill only - no corded drills near pool. Use a cordless drill for assembly and installation. To
reduce the risk of electrocution, NEVER use a corded drill in or around a pool.
Lift safely. When lifting awkward or heavy loads, have another person help you.
Double check after installation
• Before using the product, after assembly and installation, go over the instructions and procedures again
to make sure nothing has been overlooked.
• Make sure that safety labels are installed and legible.
HARDWARE PACK TOOLS REQUIRED
Qty. Description
38- #10 x 1-1/4" Screw
2- 1/4-20 x 3-1/2"
Bolt
2- 1/4" Washer
2- 1/4-20 Nylon Nut
2- Adjustable Tubes
2- Mounting Blocks
1- Cable Lock

Safe Installation

To reduce the risk of electrocution, drowning, entrapment, falls, or other
serious injury or death:
FOR ASSEMBLY:
* Cordless Drill
* 1/8" Drill Bit
* Utility Knife
* Liquid Soap or
Spray Lubricant
* Phillips Screwdriver
or screwdriver bits
Platform
Shield
Adjustable
Tube
Mounting
Block
Tread Connector
Bottom
Tread
Handrail
Stringer / leg
Upper
Tread
