- Page 1 No. 235-781-00D June 2019 D e m a n d M o o r e R e l i a b i l i t y Temptation 2000 T2X RTD Temperature Transmitter User’s Manual All product names are registered trademarks of their respective companies.
-
Page 2: Customer Support
We perform a sequence of stringent quality assurance checks on every unit we ship. If any Moore Industries product fails to perform up to rated specifications, call us for help. Our highly skilled staff of trained technicians and engineers pride themselves on their ability to provide timely, accurate, and practical answers to your process instrumentation questions. -
Page 3: Safety Messages
All Moore Industries instrumentation should only be used for the purpose and in the manner described in this manual. If you use this product in a manner other than that for which it was intended, unpredictable behavior could ensue with possible hazardous consequences. -
Page 4: Table Of Contents
Recommended Ground Wiring Practice ............. 14 CE Conformity ........................ 14 Dimensions ....................14 Installations in Hazardous Locations ............15 Specific Conditions of Use ................16 Maintaining the T2X ..................17 Certifications....................18 Warranty Disclaimer ..................22 www.miinet.com - 4 - Moore Industries-International, Inc. -
Page 5: Introduction
OF PC INPUT SIMULATOR To Serial (COM) 2-WIRE RTD or : Port of PC 2-WIRE RTD 4-WIRE RTD POTENTIOMETER 3-WIRE RTD OR DECADE OR DECADE INPUT OR DECADE RESISTANCE BOX RESISTANCE BOX RESISTANCE BOX Moore Industries-International, Inc. www.miinet.com - 5 -... -
Page 6: Installing Software
Accurate to ±0.025%, e.g. Fluke Model 87 RTD Temperature vs. Resistance Tables ITS68 and ITS90, or equivalent Personal Computer See “Installing Software” Moore Industries’ T2X Configuration Program Successfully installed on the hard disk of the specified PC Moore Industries’ Communication Cable Fuse Protected, Non-Isolated USB... -
Page 7: Managing Configuration Files
T2X, simply click “Stop”, then “Get Setup”. The screen will reflect any changes. This file can now be saved or downloaded to a different T2X. Figure 2. The Temptation 2000 PC Configuration Program provides an easy way to configure your T2X. Moore Industries-International, Inc. www.miinet.com - 7 -... - Page 8 To start the download process, click on the “Stop/Start” button at the bottom of the screen, then on the “Prog” button. This transfers the settings from the software to the memory of the connected transmitter. www.miinet.com - 8 - Moore Industries-International, Inc.
-
Page 9: Specifications
Stability (max. span): 25mA maximum All settings are made using Set Up RTD & Ohms Excitation: 1 year = ±0.12% Moore Industries’ Intelligent PC 3 years = ±0.21% 250µA, ±10% Configuration Software, and then 5 years = ±0.27% RTD Lead Wire... -
Page 10: Ordering Information
-203.19 to 300.53°C (-333.74 to 572.95°F) 100°C(180°F) Resistance Ω 0-2200Ω 0-2200Ω 0-2200Ω 30Ω Potentiometer * Transmitter will measure ranges outside of the Conformance Range with some degradation to accuracy ratings. Consult the factory for details. www.miinet.com - 10 - Moore Industries-International, Inc. -
Page 11: Installing And Connecting The T2X
Connecting the T2X in an Application Moore Industries suggests installing the T2X by first mounting the unit in its intended application, then making the electrical connections to input, output, and power. Before any installation, make sure that the unit has been bench checked to ensure that it is configured and calibrated properly for its intended application. -
Page 12: Physical Instructions For Installing An Encapsulated Hockey-Puck
A series of selected Moore Industries’ 2-Wire hockey-puck style units mounted in the LH2 enclosure (consult factory for a list of the certified instruments) are certified as an Explosion-Proof and Dust Ignition-Proof appartus in accordance with Factory Mutual Research ‘3600’... -
Page 13: Installation Of Lh Enclosure Apparatus
G½ (BSP) (C models) Mounting Holes 40 mm (1.56 in) 2-INCH PIPE MOUNTING HARDWARE 84 mm (3.30 in) 2-in Pipe Bracket Mounting Holes (4) 89 mm 61 mm (3.5 in) (2.4 in) 61 mm (2.4 in) Moore Industries-International, Inc. www.miinet.com - 13 -... -
Page 14: Recommended Ground Wiring Practice
The shield should be grounded at the receiver and not at the signal source. CE Conformity Installation of any Moore Industries’ products that carry the CE marking must adhere to the guidelines in the Recommended Ground Wiring Practices section in order to meet the EN 61326 requirements set forth in the applicable EMC directive. -
Page 15: Installations In Hazardous Locations
“COM” po ort for use in N Non-Hazardo us areas sha ll not exceed 3.0V, 300uA an d 240uW. Moore Industries-International, Inc. www.miinet.com - 15 -... -
Page 16: Specific Conditions Of Use
The “COM” port must not be used in a hazardous area. Operating ambient temperature: -40°C to +60°C The specific parameters of the mode(s) of protection can be found in Control Drawing 100-100-38 in this manual. www.miinet.com - 16 - Moore Industries-International, Inc. -
Page 17: Maintaining The T2X
Maintaining the T2X Moore Industries suggests a quick check for terminal tightness and general unit condition every 6-8 months, depending upon the severity of conditions. Things such as ambient vibration, corrosive atmospheres, extreme heat or cold, etc., can play a role in shortening the service life of any piece of electronic equipment. -
Page 18: Certifications
User’s Manual 235-781-00D T2X RTD Temperature Transmitter June 2019 www.miinet.com - 18 - Moore Industries-International, Inc. - Page 19 User’s Manual 235-781-00D T2X RTD Temperature Transmitter June 2019 Moore Industries-International, Inc. www.miinet.com - 19 -...
- Page 20 User’s Manual 235-781-00D T2X RTD Temperature Transmitter June 2019 www.miinet.com - 20 - Moore Industries-International, Inc.
- Page 21 User’s Manual 235-781-00D T2X RTD Temperature Transmitter June 2019 Moore Industries-International, Inc. www.miinet.com - 21 -...
-
Page 22: Warranty Disclaimer
Return Policy For a period of thirty-six (36) months from the date of shipment, and under normal conditions of use and service, Moore Industries (“The Company”) will at its option replace, repair or refund the purchase price for any of its manufactured products found, upon return to the Company (transportation charges prepaid and otherwise in accordance with the return procedures established by The Company), to be defective in material or workmanship.
