- Page 1 No. 235-740-00J March 2019 D e m a n d M o o r e R e l i a b i l i t y PC-Programmable Temperature Transmitter with Display User’s Manual All product names are registered trademarks of their respective companies.
- Page 2 We perform a sequence of stringent quality assurance checks on every unit we ship. If any Moore Industries product fails to perform up to rated specifications, call us for help. Our highly skilled staff of trained technicians and engineers pride themselves on their ability to provide timely, accurate, and practical answers to your process instrumentation questions.
-
Page 3: Table Of Contents
Input Type & Accuracy....................7 Ordering Information ..................... 8 Everything You Need is Included ................. 8 Default Factory Configuration ..................8 Configuring a TDY ........................What is First ........................9 What is Next ........................9 Installing the Software ....................10 Gathering the Equipment Needed ................. - Page 4 ....................Saving the Configuration Files to Disk ..............23 Retrieving a Configuration File from Disk ..............23 Retrieving a Configuration File from a Connected TDY ........... 23 Installing and Connecting the TDY ..................Connecting the TDY in an Application ............... 24 Recommended Ground Wiring Practices ..............
-
Page 5: Introduction
4-20mA. The output signal is proportional (or, by user designation, inversely proportional) to the input. Figure 1. Use the PC-Programmable TDY as an interface between sensors and controllers 4-20mA Isolated 705.74... -
Page 6: Specifications
Specifications Performance Power Supply and Load Input Accuracy: Decimal Points: Performance Display (Continued) Effect: Negligible within Refer to Table 2 Automatically adjusting (Continued) power and load limits decimal point with a two Output Accuracy: 4.8µA Over-Voltage Protection: (0.03% of 4-20mA span) decimal place maximum 4V max., on Input;... -
Page 7: Input Type & Accuracy
Table 2. Input Types, Ranges, Minimum Span and Maximum Range Specifications, and Accuracy of the TDY Maximum Conformance Minimum α ∗ Input Accuracy Input Type Ohms Range Range Span -100 to 560°C ±0.11°C ±0.2°F -50 to 500°C Platinum 0.003750 1000 -148 to 1040°F -58 to 932°F ±0.21°C ±0.38°F -240 to 960°C 100, 200, 300, -200 to 850°C... -
Page 8: Ordering Information
2-inch pipe (i.e. BH2NGP) To order, specify: Unit / Input/ Output / Power [Housing] Model Number Example: TDY / PRG / 4-20MA / 10-42DC [BH2NGP] Model and Serial Numbers Moore Industries uses To order cables, specify Moore Industries’ part number... -
Page 9: Configuring A Tdy
• Saving the Default Configuration No Transmitter Needed (Keeping What You’ve Got Safe) It is not necessary to connect the TDY to a PC to • Selecting Input Type, Wiring Configuration, create Configuration Files. The Configuration etc. Program can be run without connecting a transmitter, and most operating parameters can be set without •... -
Page 10: Installing The Software
Installing the Configuration Gathering the Equipment Needed It is possible to create a Configuration File for a TDY Software without ever connecting the transmitter to a PC. Refer to Table 5 for the equipment needed. Most TDY operating parameters can be setup, saved... - Page 11 Figure 2. Use the PC Configuration Software to program the TDY 327.64 TDY COMM CABLE 803-040-26 FOR NON-ISOLATED D E G C 803-039-26 FOR ISOLATED 804-030-26 FOR USB POWER TO SERIAL TO USB SOURCE (COM) PORT (COM) PORT OF PC 10-42Vdc OF PC – – CALIBRATED – INPUT CURRENT...
-
Page 12: Pc Configuration Software Summary
TDY. When certain options are This column will change to reflect the values on the selected, these scroll bars are renamed to adjust the rest of the screen when you program the TDY with its reverse output and the loop test. new values. -
Page 13: Keeping What You've Got Safe-Using The "Get Setup" Function
Keeping What You’ve Got Safe— Note: File names must follow the DOS convention; Eight- Using “Get Setup” character maximum, all lower case, no suffix. Every TDY is shipped from the factory with a The Configuration Program adds Configuration File already installed in its memory. a suffix to the file name automatically. This file is comprised of either the factory default set of operating parameters, or of the set of parameters Answer “Yes”... -
Page 14: Selecting Input Type, Wiring, Etc
Settings on the Configuration Program Screen do Use the selection tools in the Input Type box to not take effect in the unit until the Configuration File choose the sensor type that the TDY will be reading. is downloaded. Skip to Step 6 for instructions on Moore Industries suggests saving the initial settings getting the settings programmed resident in the transmitter before making any changes into TDY nonvolatile memory. -
Page 15: Scaling The Input (Also: Setting Reverse Output)
Select one of these options: (also: Setting Reverse Output) Download the current settings into the This parameter allows the user to set the TDY to connected transmitter’s memory (Go to Step 6), or scale its output in response to a portion of the total range of the selected input type. -
Page 16: Setting The Display
Figure 7. The pull-down menu lets you select what the TDY displays. Scaling the input display is a simple procedure. First, click “Scale” on the radio button in Figure 8. (Note that if you have the pull-down menu in Figure 7 set to “Output”, the Display radio button will... -
Page 17: Scaling The Output
Step 3 on page 9. page 9). To start the Download Process, click on the To set the output scaling for the Input to the TDY: “Stop” button at the bottom-center of the screen. This will enable the “Prog” button. -
Page 18: Trimming The Input
Trimming the Input Trimming the Output Use this feature of the TDY to enhance the accuracy The TDY has a function that allows precise control of the transmitter by precisely matching its actual over its output. Note that to activate this function, a... -
Page 19: Setting Miscellaneous Functions-Engineering Unit Readout, Input Filtering, Upscale Or Downscale Drive, And Broken Wire Detection
Working with a Millivolt Input have a transmitter hooked up to the PC in order to set When the transmitter is connected to a PC, the “TDY these parameters and save them in a Configuration Status” section of the Main Configuration screen File. -
Page 20: Setting Output Damping
Using the Loop Test The Output Damping function of the TDY allows the The TDY Loop Test feature allows the user to employ user to introduce a delay into the response of the the transmitter’s output to “trim” other instruments in transmitter in order to minimize the effect of any the loop. -
Page 21: Creating A Custom Linearization Table
(viewable with the Configuration Program). This section explains how to create a Custom Linearization Table for downloading into TDY memory. The instructions assume that the Configuration Program has been loaded successfully. Moore Industries also suggests saving the initial settings resident in the transmitter before making any changes. - Page 22 10. Click on the “Prog” (Program) button to download the output trim settings into the transmitter memory. CAUTION: Any time a connected TDY is “programmed” by downloading a Configuration File into memory, ALL of the configuration parameters resident in the transmitter memory at the time of the download are OVERWRITTEN. This includes things like: tag name, calibration date, trim values, etc.
-
Page 23: Managing Configuration Files
The parameters can now be edited and/or downloaded into the memory of a connected TDY. Retrieving a Configuration File from the Connected TDY Make sure a transmitter is connected and communicating properly with the Configuration Program, then simply click on the “GetSetup” button. -
Page 24: Installing And Connecting The Tdy
• The maximum length of unshielded input and output signal wiring should be 2 inches. The TDY is available only in the HP housing style, but may be enclosed in any one of several types of certified or uncertified connection heads. Consult your Note: local Moore Industries’... -
Page 25: Dimensions
(.70 in) 62.26mm (3.25 in) (2.45 in) 43.18mm (1.70 in) 63.60mm (2.50 in) FRONT VIEW SIDE VIEW Figure 15. The Dimensions of the D-Box housing for the TDY unit. Conduit Conduit Fitting Fitting 130 mm (5.12 in) Body Body Bezel... -
Page 26: Dimensions
Figure 16. The Dimensions of the explosion-proof housing for the TDY unit. 129mm (5.06 in) 10mm BOTTOM VIEW TOP VIEW (.38 in) 53mm 102mm (2.09 in) 68mm (4.00 in) 16.203 65mm 124mm (2.69 in) (2.55 in) (4.90 in) 84mm (3.31 in) 25mm (1.00 in) -
Page 27: Installation In Hazardous Locations
300mA and 240mW. be provided with supply transient protection external to the apparatus such that the voltage at the supply terminals of the TDY does not exceed 58.8V peak or Specific Conditions of Use 58.8Vdc. The following instructions must be adhered to when... - Page 28 TDY that the voltage at the supply terminals of the TDY does not exceed 119V peak or 119Vdc.
-
Page 29: Operating The Tdy
This condition is “downloadable” to a TDY. It is intended to provide the user with the ability to monitor general trends on the input, functioning within the rated accuracy whenever input is within the conformance range, but inherently less accurate outside the range. -
Page 30: Contacting Customer Support
Factory phone numbers are listed on the back cover of this manual. If problems involve a particular TDY, there are several pieces of information that can be gathered from the installation before the factory is called that will help our staff get the necessary answers in the shortest time possible. -
Page 31: Intrinsically Safe Diagrams
This page contains the installation diagram for the tion instructions earlier in this manual for units that are TDY carrying the intrinsically safe option. It also in- to operate in areas requiring intrinsically safe instru- cludes guidelines for setting up zener barriers neces- mentation. - Page 32 Demand Moore Reliability...
-
Page 33: Return Procedures And Warranty Info
Demand Moore Reliability... - Page 34 4. Ship the equipment to the Moore Industries location nearest you. The returned equipment will be inspected and tested at the factory. A Moore Industries representative will contact the person designated on your documentation if more informa- tion is needed. The repaired equipment, or its replacement, will be returned to you in ac- cordance with the shipping instructions furnished in your documentation.
