Circular filling system
1 Tank
2 Measuring device
3 Batching valve
4 Vessel
Linear filling system
2
1 Tank
2 Measuring device
3 Batching valve
4 Vessel
6.2

Mounting the measuring device

6.2.1

Required tools

For sensor
For flanges and other process connections:
• Screws, nuts, seals etc. are not included in the scope of supply and must be provided by
the customer.
• Appropriate mounting tools
6.2.2

Preparing the measuring device

1. Remove all remaining transport packaging.
1
3
4
Installation
1
2
3
4
A0003761
A0003762
