Dosimag Modbus RS485
Weight
Materials
Endress+Hauser
Compact version
Weight in SI units
DN [mm]
4
8
15
25
Weight in US units
DN [in]
⁵⁄₃₂
⁵⁄₁₆
½
1
Transmitter housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4308 (304)
Device plugs
Electrical connection
Plug M12x1
Sensor housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4301 (304)
Measuring tube
Stainless steel 1.4301 (304)
Liner
PFA
Electrodes
• 1.4435 (316L)
• Alloy C22, 2.4602 (UNS N06022)
• Platinum
• Tantalum
Weight [kg]
2.8
2.8
2.8
4.3
Weight [lbs]
6.17
6.17
6.17
9.48
Material
• Socket: Stainless steel, 1.4404 (316L)
• Contact housing: Polyamide
• Contacts: Gold-plated brass
Technical data
