10.4.5 Configuring the communication interface
The Communication submenu guides you systematically through all the parameters that
have to be configured for selecting and setting the communication interface.
Navigation
"Setup" menu → Communication
‣
Communication
Bus address
Baudrate
Data transfer mode
Parity
Byte order
Assign diagnostic behavior
Failure mode
Parameter overview with brief description
Description
Enter device address.
Define data transfer speed.
Select data transfer mode.
Select parity bits.
Select byte transmission sequence.
User entry / Selection
1 to 247
• 1200 BAUD
• 2400 BAUD
• 4800 BAUD
• 9600 BAUD
• 19200 BAUD
• 38400 BAUD
• 57600 BAUD
• 115200 BAUD
• ASCII
• RTU
Picklist ASCII option:
• 0 = Even option
• 1 = Odd option
Picklist RTU option:
• 0 = Even option
• 1 = Odd option
• 2 = None / 1 stop bit option
• 3 = None / 2 stop bits
option
• 0-1-2-3
• 3-2-1-0
• 1-0-3-2
• 2-3-0-1
Commissioning
Factory setting
247
19200 BAUD
RTU
Even
1-0-3-2
