WARNING: Never expose eyes or skin to UVC light from any source.
• Looking directly at the UVC light may cause permanent eye damage or blindness.
• Never operate the UV-Aire™ Air Purifying System out of the plenum.
• Designed for a closed duct system. Do not mount near a supply or a return air opening.
• All duct openings in direct line of site of the UV light must be sealed with aluminum tape or equivalent
sealing methods.
WARNING: UV light will break down plastic materials not rated for UV exposure:
(Examples: wire insulation, fl ex duct, drain pans and humidifi ers)
• The unit must be mounted at least 30" from the above stated type of materials.
• If it is necessary to mount the unit in direct line of sight of these types of materials, they must be shielded
with aluminum foil, aluminum foil tape, or sheet metal.
WARNING: DO NOT install this equipment outdoors except within a package unit air handler that is fully
protected from moisture entry.

INDICATION FOR USE

This product is not sold as a medical device and is not for the purpose of diagnosis of any disease or
condition nor for use in the mitigation, treatment, or prevention of any disease or condition.

GENERAL INFORMATION

There are different size units available, depending on the tonnage of your HVAC system. See chart below
for determining the needs of your home.
The FlexMount™ UV-Aire™ system is provided with a unique patented, magnetically-attached Mounting
Bracket Assembly. The mounting bracket assembly may be rotated and/or extended relative to the mounting
surface, to provide maximum fl exibility in mounting positions and confi gurations.
A refl ective aluminum shield is included which may optionally be used to shield wiring, ductwork and parts
which could be damaged by UVC exposure, and/or concentrate the UVC rays in a particular area such as
the A-coil.
The part of the lamp bracket to which the lamp is attached may be separated from the mounting bracket
assembly, and used for mounting the lamp through a delta plate covering the end of the A-coil, or for
mounting the lamp inside of a plenum or air duct.
MODEL VOLTS
UV-12FM 24
UV-14.5FM 24
WARNING: never expose eyes or skin to UVC light from any source. Looking directly at the UVC light may cause permanent eye damage or
blindness. Never operate the UV-Aire™ AirPurifying System out of the plenum. Avoid touching the glass portion of the lamp with your hands.
P/N 78010015000 RevB 02/18
WATTS
AMPS HZ
(LAMP)
0.8 50/60 15
0.8 50/60 17
UVC INTENSITY
MAX AIR TEMP °F
176°
176°
Page 2 of 8
RECOMMEND-
ED HVAC TON-
AT 1 METER
NAGE
43 μW/cm2 1.5-3
54 μW/cm2 1.5-5
