UV-AIRE™ AIR PURIFYING SYSTEM
UV-C light inhibits the growth and reproduction of germs and bacteria that circulate through a
homes' heating and air conditioning system. The treatment is a safe, silent, and proven way
to make your home a healthier place to live.
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE PROCEEDING WITH THE INSTALLATION
LEAVE THE INSTALLATION INSTRUCTIONS WITH THE OWNER/OPERATOR OF THE DEVICE
AFTER OPENING THE CARTON, UNPACK AND INSPECT THE UNIT AND LAMP FOR DAMAGE.
SAFETY CONSIDERATIONS
WARNING: Never expose eyes or skin to UVC light from any source.
• Looking directly at the UVC light may cause permanent eye damage or blindness.
• Never operate the UV-Aire™ Air Purifying System out of the plenum.
WARNING: UV light will break down plastic materials not rated for UV exposure:
(Examples: wire insulation, flex duct, drain pans and humidifiers)
• The unit must be mounted at least 30" from the above stated type of materials.
• If it is necessary to mount the unit in direct line of site of these types of materials, they must be shielded
with aluminum foil, aluminum foil tape, or sheet metal.
(For use with 12", 18" and 28" Field Controls Lamps)
(120/240 volt application)
DO NOT INSTALL THIS UNIT IF ANY DAMAGE IS NOTICEABLE.
Model: UV-E
ITEMS INCLUDED IN KIT:
1-UV-E power unit (NEMA3 housing)
1-Mounting Template
4-Sheet metal mounting screws
1-Angled mounting bracket
1-Flat mounting bracket
1-Instruction Sheet
1-Wing nut
2-Hex nuts
1-Lamp
Advertisement
Related Manuals for Field Controls 46427300
Summary of Contents for Field Controls 46427300
- Page 1 UV-AIRE™ AIR PURIFYING SYSTEM Model: UV-E (For use with 12”, 18” and 28” Field Controls Lamps) (120/240 volt application) ITEMS INCLUDED IN KIT: 1-UV-E power unit (NEMA3 housing) 1-Mounting Template 4-Sheet metal mounting screws 1-Angled mounting bracket 1-Flat mounting bracket...
- Page 2 GENERAL INFORMATION This product is not sold as a medical device and is not for the purpose of diagnosis of any disease or condition nor for use in the mitigation, treatment, or prevention of any disease or condition. There are different size units available, depending on the square footage of your home. See chart below for determining your homes needs.
- Page 3 WARNING: Disconnect electrical power supply before wiring 9. Connect to an appropriate power source such as an AC power disconnect box or to a circuit breaker panel. (See Figure 8) 10. Determine length of wire and conduit necessary according to power connection and install wiring conduit and water tight connector as shown in example figure 4.
- Page 4 Figure C Figure D NSTALLATION This unit is listed for use with Field Controls’ lamps ONLY. You will need to determine proper lamp selection based on duct size and desired configuration. (Refer to configuration table on page 6 of this manual) 16.
- Page 5 18. Swing securing bracket over end of lamp and hand-tighten the provided wing nut on stud. (See Figure 13) Figure 13 19. Plug ballast plug into end of lamp and reconnect power supply. (See Figure 14) Figure 14 20. Flip the red power switch to the on position. (Light on switch should be on indicating power.) 21.
- Page 6 III. BULB MOUNTING BRACKET SELECTION AND INSTALLATION The UV-AIRE units come with an angled mounting bracket and flat mounting bracket to position the bulb either straight or at an angle. Choose one or the other bracket method best suited for your needs. Refer to the configurations chart below when making your selection.
- Page 7 46365506 28” 46365403 46365506 For replacement parts, contact your local heating service company. Any questions, please contact Field Controls at: Phone: 252-522-3031 Fax: 252-522-0214 Email: sales@fieldcontrols.com WARNING: Never expose eyes or skin to UVC light from any source. Looking directly at the UVC light may cause permanent eye damage or blindness.
-
Page 8: Warranty Information
ONE YEAR LIMITED WARRANTY (excluding lamps, which have a 90 day warranty, from day of installation) The products of The Field Controls Co. are warranted to be free from defects in material and workmanship under normal use for five years from date of manufacture.
