UV-AIRE

ITEMS INCLUDED IN KIT:

1- UV-Aire UV-1500 unit
10- sheet metal mounting screws
2- drop ceiling cover plates
4- wall and drop ceiling mounting brackets
1- Ultra Violet lamp
1- instruction sheet
1- 2x4 electrical conduit box and cover
4- intake air filters
1- carbon filter
*For best results, operate the UV-1500
continuously 24 hours a day.
UV-C light inhibits the growth and reproduction of germs and bacteria in the air of a home or office. The
treatment is a safe, silent, and proven way to make your home or office a healthier place to live and work.

SAFETY CONSIDERATIONS

WARNING: Never expose eyes or skin to UVC light from any source.
• Looking directly at the UVC light may cause permanent eye damage or blindness.
• Never operate the UV-Aire Air Purifying System with the UV chamber open.
WARNING: DO NOT mount this unit outdoors.
• This product is designed for indoor installation only.
AFTER OPENING THE CARTON, UNPACK AND INSPECT THE UNIT AND LAMP FOR DAMAGE.
DO NOT INSTALL THIS UNIT IF ANY DAMAGE IS NOTICEABLE.
This product is not sold as a medical device and is not for the purpose of diagnosis of any disease or condition nor for
use in the mitigation, treatment, or prevention of any disease or condition.
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE PROCEEDING WITH THE INSTALLATION.
This device MUST be installed by a qualified agency in accordance with the manufacturer's installation instructions. The definition of
a qualified agency is: any individual, firm, corporation or company which either in person or through a representative is engaged
in, and is responsible for, the installation and operation of HVAC appliances, who is experienced in such work, familiar with all the
precautions required, and has complied with all the requirements of the authority having jurisdiction.
Installed By:
AIR PURIFYING SYSTEM
®
Model: UV-1500C
Please retain these instructions after installation.
Phone:
www.fieldcontrols.com
Installation Date:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UV-AIRE UV-1500C and is the answer not in the manual?

Questions and answers

Related Manuals for Field Controls UV-AIRE UV-1500C

Summary of Contents for Field Controls UV-AIRE UV-1500C

  • Page 1 UV-AIRE ® ITEMS INCLUDED IN KIT: 1- UV-Aire UV-1500 unit 10- sheet metal mounting screws 2- drop ceiling cover plates 4- wall and drop ceiling mounting brackets 1- Ultra Violet lamp 1- instruction sheet 1- 2x4 electrical conduit box and cover 4- intake air filters 1- carbon filter *For best results, operate the UV-1500...
  • Page 2 INDICATION FOR USE This product is not sold as a medical device and is not for the purpose of diagnosis of any disease or condition nor for use in the mitigation, treatment, or prevention of any disease or condition. GENERAL INFORMATION Model Volts Amps Hz Watts UV-1500C...
  • Page 3 FOR AREA OR ROOM OPERATION Place the UV-1500C in the desired area; plug the power cord into a standard 120-volt wall receptacle. Turn the speed control knob clockwise to turn on the unit and to adjust the motor/fan speed to the desired airflow. (See Figure 1) After the fan has started, the LED light will show a continuous “GREEN”...
  • Page 4 SUSPENSION OR DROP CEILING OPTION The UV-1500C must be wired in accordance with the National Electrical Code and any applicable local codes. The UV-1500C must be hard-wired using metal-shielded cable, BX cable or similar wiring methods. Install the four mounting brackets onto the back of the housing securing them with the eight mounting screws.
  • Page 5 Install eyelet screws or other appropriate anchors into the ceiling joists above the location where the unit will be installed. If installing the UV-1500C into 4' x 2' tile grid, install an additional suspended ceiling tee bracket into the ceiling grid to form a 2' x 2' tile location. (See Figure 13) Install the UV-1500C into the suspended ceiling grid then install support wires (16 gauge wire) or other suspended ceiling support method between the installed ceiling anchors and the four mounting brackets on the back of the UV-1500C.
  • Page 6 MAINTENANCE Replace 12"x 12" intake filter every 90 days, replace carbon outlet filter every 12 months. Replace your UV-Aire Air Purifying System lamp once a year to maintain the lamp’s maximum output intensity. The lamp should operate continuously for maximum lamp life and light effectiveness. REPLACEMENT PROCEDURES REPLACING THE UV LAMP VERY IMPORTANT: Turn the speed control switch on unit to 'OFF' position and unplug unit from outlet or turn...
  • Page 7 Replace the lamp by first guiding the end of the lamp through the hole on the left side of the UV chamber. Next, guide the other end of the lamp through the hole on the right side of the UV chamber. Hold the lamp in position while rotating the swivel bracket into position.

  • Page 8: Limited Warranty

    Field Controls Direct Vent Systems (FDVS), Field Oil Vent Kits (FOVP), and ComboVents (CV). Field Controls warrants that the products listed below shall be free from defects in material and workmanship under normal use for the limited period indicated, from the date of purchase by the consumer, subject to the provisions 1-8 below.
