Output signal

14

Output

HART
Signal coding
Data transmission rate
Galvanic isolation
PROFIBUS PA
Signal coding
Data transmission rate
Galvanic isolation
FOUNDATION Fieldbus
Signal coding
Data transmission rate
Galvanic isolation
Switch output
For HART devices, the switch output is available as an option. See product structure, feature 20:
"Power Supply, Output", option B: "2-wire; 4-20mA HART, switch output"
Devices with PROFIBUS PA and FOUNDATION Fieldbus always have a switch output.
Switch output
Function Open collector switching output
Switching behavior Binary (conductive or non-conductive), switches when the programmable switch
point is reached
Failure mode non-conductive
Electrical connection values U = 16 to 35 V
Internal resistance R
The voltage drop at this internal resistance has to be taken into account on
planning the configuration. For example, the resulting voltage at a connected
relay must be sufficient to switch the relay.
Insulation voltage floating, Insulation voltage 1 350 V
Switch point freely programmable, separately for switch-on and switch-off point
Switching delay freely programmable from 0 to 100 s, separately for switch-on and switch-off
point
Number of switching cycles corresponds to the measuring cycle
Signal source • Level linearized
device variables • Distance
• Terminal voltage
• Electronic temperature
• Relative echo amplitude
• Diagnostic values, Advanced diagnostics
Number of switching cycles unlimited
FSK ±0.5 mA over current signal
1 200 Bit/s
Yes
Manchester Bus Powered (MBP)
31.25 kBit/s, voltage mode
Yes
Manchester Bus Powered (MBP)
31.25 kBit/s, voltage mode
Yes
, I = 0 to 40 mA
DC
< 880 Ω
I
Micropilot FMR51, FMR52
to power supply aund 500 V
DC
Endress+Hauser
to ground
AC
