CertainTeed Bufftech Installation Instructions Manual page 35

Post & Rail Fence
Includes: Crossbuck, 2-Rail, 3-Rail and 4-Rail
stagger rail ends For
greater strength
dig holes 30"
deeP or to
Frost line
Post holes
5 x 5 POSTS = 12"
HOLD RAILS IN POST WITH LOCk RING.
dePress locK ring tabs
insert in rail and
Post centers
5 x 5 POSTS = 96"
release
ALLOW 1-1/2" GAP ON HINGE SIDE
oF gate and 1-1/4" on latch
side oF gaTE HARDWare
Post suPPorT OPTIONS:
inserT ALUMINUM GAte Post stiFFener
inside Post For FASTER, CLEANER INSTallation
USE (2) PIECES OF 1/2" REBAR IN HINGE,
rebar
seParator cliP
laTCH AND END POSTS. POSITION REBAR
IN OPPOSING CORNERS OF EACH POST WITH
rebar seParator cliPs
1/2" REBAR
attach braces
on both sides oF
gate in identical
Positions
33
