Norfolk 1 - CertainTeed Bufftech Installation Instructions Manual

Privacy Fence
Includes: Norfolk 1
hold toP rails
IN POST WITH
locK ring
HOLD BOTTOM
rails in Post
WITH LOCk
ring
5 X 5 POSTS = 95-1/8"
dig holes 30"
deeP or to
Frost line
Post holes
5 X 5 POSTS = 12"
Post centers
SECURE MID BRACE TO PICkETS
WITH SCREWS, at THE SAME
location on both sides oF
the Fence
ALLOW 1" FOR HINGE
and 3/4" For laTCH SYSTEM
ALLOW CLEARANCE
For gaTE SWING
Post suPPort OPTIONS:
inserT ALUMINUM GAte Post stiFFener
inside Post For FASTER, CLEANER INSTallation
USE (2) PIECES OF 1/2" REBAR IN HINGE,
rebar
seParator cliP
laTCH AND END POSTS. POSITION REBAR
IN OPPOSING CORNERS OF EACH POST WITH
rebar seParator cliPs
1/2" REBAR
25
