Semi-Private Fence
Includes: Millbrook
locK toP rail in Post
WITH #8 X 3/4" SCREW
HOLD TOP AND BOTTOM
rails in Post
WITH LOCk RING
Post holes
5 X 5 POSTS = 12"
Post centers
5 X 5 POSTS = 96"
dig holes 30"
deeP or to
Frost line
SECURE MIDDLE
rail to PicKets
WITH (2) #8 X 1-1/2"
SCREWS, CAPS
AND Washers
ALLOW 1" FOR HINGE
and 3/4" For laTCH SYSTEM
ALLOW CLEARANCE
For gaTE SWING
Post suPPorT OPTIONS:
inserT ALUMINUM GAte Post stiFFener
inside Post For FASTER, CLEANER INSTallation
USE (2) PIECES OF 1/2" REBAR IN HINGE,
rebar
seParator cliP
laTCH AND END POSTS. POSITION REBAR
IN OPPOSING CORNERS OF EACH POST WITH
rebar seParator cliPs
1/2" REBAR
