Galveston - CertainTeed Bufftech Installation Instructions Manual

Privacy Fence
Includes: Galveston
Galveston with CertaGrain
hold toP rails
IN POST WITH
locK ring
HOLD BOTTOM
rails in Post
WITH LOCk
ring
®
HOLD MIDDLE RAILS
IN POST WITH
locK ring
Post centers
5 X 5 POSTS = 96-1/8"
dig holes
ADD 1/2" TO POST CENTERS
48" deeP
WHEN USING END CHANNELS
Post holes
5 X 5 POSTS = 12"
FILL END, LINE AND CORNER POSTS WITH
CONCRETE TO 1" BELOW MIDDLE RAIL. USE (2)
PIECES OF 1/2" REBAR IN EACH POST. LENGTH
OF REBAR SHOULD EXTEND FROM BOTTOM
OF HOLE TO 4" BELOW MIDDLE RAIL
LENGTH OF ALUMINUM
INSERT SHOULD EXTEND
FROM BOTTOM OF POSTS
TO 4" BELOW MIDDLE RAIL.
LINE POST STIFFENER
ALUMINUM INSERT
Texture
PicKets For this stYle
ARE TONGUE AND GROOVE
tongue riPPed oFF last PicKet
to sit Flush against Post
NOTE: 3 HINGES ARE REQUIRED
For galVESTON
ALLOW 1" FOR HINGE
and 3/4" For laTCH SYSTEM
ALLOW CLEARANCE
For gaTE SWING
Post suPPorT OPTIONS:
inserT ALUMINUM GAte Post stiFFener
inside Post For FASTER, CLEANER INSTallation
USE (2) PIECES OF 1/2" REBAR IN HINGE,
rebar
seParator cliP
laTCH AND END POSTS. POSITION REBAR
IN OPPOSING CORNERS OF EACH POST WITH
rebar seParator cliPs
1/2" REBAR
