  • Page 1 DYNAPAC CA121/141 OPERATION O121EN4 Box 504, SE-371 23 Karlskrona, Sweden Phone: +46 455 30 60 00, Fax: +46 455 30 60 30 www.dynapac.com...
  • Page 2 ILF015WO1...
  • Page 3 CA121: PIN (S/N) *60311000* CA141: PIN (S/N) *60410600* The CA121 is a 4-ton and the CA141 is a 5-ton vibratory roller designed for compaction operations in pipe trenches, on road shoulders and in cramped spaces in connection with refilling work. The rollers are also suitable for repair work on dams, power stations, parking lots and airfields.
  • Page 4: Table Of Contents

    This manual contains instructions for the operation and use of the roller. For care and maintenance, see the Proposition 65 Warning ”MAINTENANCE, CA121/141” manual. Diesel engine exhaust and some of its Remember that when you start and drive a constituents are known to the State of...
  • Page 5: Safety Instructions (Also Read The Safety Manual)

    The noise level will vary depending on the surface you are working on. 17. Do not make any changes or modifications on the roller that could affect safety. Changes may only be made with Dynapac’s written consent. 18. Do not use the roller until the hydraulic fluid has reached its normal working temperature.
  • Page 6: Safety When Driving

    ON, driving speed and raising the center of Max 20° gravity (as with accessories) may cause the machine or 36% to topple even on a smaller slope than specified here. Fig. 2 Tipping angle on side slopes CA121/141 O121EN4...
  • Page 7: Safety (Optional)

    The operator must make sure that nobody is in the working area during operation. Retract the strike-off blade to transportation mode at the end of each working period. Always lower the blade to the ground before leaving/parking the roller. Fig. 3 Strike-off blade CA121/141 O121EN4...
  • Page 8: Safety Decals, Location And Description

    SAFETY DECALS, LOCATION AND DESCRIPTION 12 7 10 CA121/141 O121EN4...
  • Page 9: Safety Decals, Location And Description

    Read the Do not touch. instruction manual. Sound Power level CA121 791275 110 kPa 16 psi Mass 991990 Diesel fuel Hoisting plate Tire pressure Sound Power level CA141 Alt. 1 Alt. 2 Biological Hydraulic = Optional hydraulic fluid fluid CA121/141 O121EN4...
  • Page 10: Machine And Engine Plates

    John Deere Engine Manufacturing ISO 9001 Registered For Engine Service and Parts Call 1-800-JD ENGINE JOHN DEERE Engine Serial Number *CD3029TXXXXXX* 3029TF270 Abs. Fig. 6 Engine Coeff. 1. Type plate DEERE&COMPANY MOLINE ILLINOIS MADE IN FRANCE 2. EPA sign (USA) CA121/141 O121EN4...
  • Page 11: Instruments And Controls

    Starter switch Temperature gauge - coolant Pocket containing safety and Oil pressure gauge instruction manuals Voltmeter Working lights ON/OFF Fuel gauge Strike-off blade UP/DOWN Warning lamp, charging Tachometer/Hourmeter Hazard beacon ON/OFF Parking brake ON/OFF Preheating ON/OFF = Optional CA121/141 O121EN4...
  • Page 12: Instruments And Controls, Functional Description

    Press to honk the horn. Rev control Released/engaged by the center button. Pull out to increase engine revs. Push in to reduce. Twist the handle for fine adjustment. Counter-clockwise = increase, clockwise = reduce. Minimum revs: 1000 r/min; Max: 2200 r/min. CA121/141 O121EN4...
  • Page 13 Stop the engine and locate the fault. Hazard beacon The rotating hazard flasher is on in ON (Optional) mode. Preheating button Press the preheating button for 30 seconds before attempting to start the engine. CA121/141 O121EN4...
  • Page 14: Before Starting

    3. Reserve brake If the parking brake is not applied, the roller 6. Voltmeter may start to roll when you start the engine 7. Fuel gauge on sloping ground. 9. Parking brake knob 12. Starter switch 16. Warning lamp, charging CA121/141 O121EN4...
  • Page 15 ROPS is fitted on the roller, and wear a protective helmet. Always replace the seat belt (1) with a new one if it is worn or has been subjec- ted to a heavy load. Fig. 11 Operator’s station 1. Seat belt CA121/141 O121EN4...
  • Page 16: Starting

    Make sure that ventilation (extraction) is adequate if the engine is run indoors (risk of carbon monoxide poisoning). CA121/141 O121EN4...
  • Page 17: Operation

    The engine stops when the reserve brake knob is pressed. The control knob must be pulled out before the engine can be restarted. The Forward/Reverse control must be in neutral before the engine can be restarted. Fig. 14 Instrument panel, left side 3. Reserve brake CA121/141 O121EN4...
  • Page 18: Operation/Vibration

    The lever (15) has two modes. Upward – Raising the blade. Downward – Lowering the blade. Lower the blade before leaving/parking the machine. Use the blade only when driving FORWARD. Fig. 16 Instrument panel and controls 15. Lever CA121/141 O121EN4...
  • Page 19: Braking

    Fig. 18 Instrument panel and controls 1. Forward/Reverse lever working temperature. 2. Vibration ON/OFF 9. Parking brake 11. Rev control CA121/141 O121EN4...
  • Page 20: Braking

    Check the instruments to see if any faults are indica- ted, switch off all lights and other electrical functions. Turn the starting knob (12) to position O. Lower the instrument cover and lock it. Fig. 19 Instrument panel and controls 12. Starter switch CA121/141 O121EN4...
  • Page 21: Parking

    Lock the engine hood, too. Fig. 21 Battery disconnecter 1. Handle Strike-off blade (Optional) Always lower the blade to the ground before leaving/parking the roller. Fig. 22 Strike-off blade CA121/141 O121EN4...
  • Page 22: Instructions For Lifting

    Remember to restore the articulation interlock to open mode before driving again. Release the cotter (2) and retract the locking arm (1). Refit the cotter (2). Fig. 25 Left side of articulation 1. Articulation lock in open mode 2. Cotter CA121/141 O121EN4...
  • Page 23: Towing/Retrieval

    When towing/retrieval a machine, the towing device must be connected to both lifting holes. Pulling forces should act longitudinally on the machine as illustrated. Maximum gross pulling force 80 kN (18 lbf). Fig. 28 Towing Restore all of the above towing items. CA121/141 O121EN4...
  • Page 24: Transportation

    Clamp down the roller with lashing strap at all four corners; decals (3) indicate the fixing points. Fig. 29 Chocking the drum/frame Remember to restore the articulation interlock 1. Chock to open mode before starting the roller again. 2. Block up 3. Lashing strap CA121/141 O121EN4...
  • Page 25: Operating Instructions - Summary

    Press the emergency stop knob to stop the engine, chock the drum and the wheels. 15. Lifting: See the operation manual. 16. Towing: See the operation manual. 17. Transport: See the operation manual. 18. Retrieval: See the operation manual. CA121/141 O121EN4...
