Page 1: Getting Started
Getting Started TLE983x Evaluation Board for TLE983x Devices V1.2 20. Dec. 2011... - Page 2 Getting Started with TLE983x Evaluation Board Hardware Development Tools (Example based on Keil PK51) Downloading the Firmware 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 2...
- Page 3 Connector Connectors Supply for Monitor Input Switches Supply Jumper for current Monitor measurement Input Switches TLE 983x, Pin 1 Reset Switch LEDs for DAP Connector, Pin 1 GPIOs Connector 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 3...
- Page 4 (pin 1 to red wire) Find more information on the miniwiggler (source of supply and technical information) on http://www.infineon.com/miniWiggler Supply the board on V (6V-27V DC) Connect the miniWiggler to the PC 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 4...
- Page 5 Install IFX DAS from http://www.infineon.com/DAS Current version is V3.3.1 Start μVision Note: DAS, Keil and DAVE are also included in the Evaluation-Board-CD in the folder X:\Tools 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 5...
- Page 6 Step: Development Tools – Setup with Keil Start the μVision tool from Keil Start or create a project Write or modify the code Build the project 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 6...
- Page 7 Step: The Project Create or open a project Build the binary 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 7...
- Page 8 Step: Debug Options Debug Option 1: Infineon miniWiggler with Keil PK51 µVision Debug Option 2: iSystem (see iSystem’s User’s Manual) 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 8...
- Page 9 Download the FW - Final Progress Download to the target via Infineon miniWiggler can be started in the μVision Flash option on top of the window. 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 9...
- Page 10 Addendum Board Schematic • and Layout • of the TLE983x Evaluation Board See Evaluation-Board-CD in the folder: X:\Documentation\Evaluation_Board\TLE983xEVB 4/3/2012 Copyright © Infineon Technologies 2009. All rights reserved. Page 10...
