Quick Start

Check out
Check that the power supply has been destroyed or not. If there is any flaw,
please contact the vendor.
Make sure the AC input voltage of power supply accord with the standards
of your country or area.
If the 2 terms above are right, please turn on the power supply.
Voltage Set
Press key to make the preset
D V/A
voltage light "V" bright, and it
means you can set voltage value.
Press
A
B
cursor to position
knob , the voltage value will rise
or decline 1V.
Current Set
Press key to make the
D V/A
preset current light "A" bright, and
it means you can set current value.
Press
B
A
cursor to position
knob , the current value will
rise or decline 1A.
Output Operation
Press key to make the
On/Off
output state on, and the voltage
and current value on the LED will
wink for 3 seconds, then the LED
will display the actual output value.
And the " OFF" light will be off, that
means the power supply is working.
Press key again, the output
On/Off
will be off.
key, move the
, screw the
B
key, move the
, screw the
A
