Chapter2 Quick Start; Brief Introduction - ITech IT6800A Series User Manual

This chapter introduces the front panel, the rear panel, key functions and VFD
display function of the power supply, make sure that you can quickly know the
appearance, instruction and the key function before you operate the load, Help
you make better use of this series of power supply.

2.1 Brief Introduction

IT6800A/B series power supply is single output DC programmable power
supply, which support panel programming and offer OCP and OVP.
Furthermore, built-in RS232/USB communication interface is suitable for either
bench or rack mounted operation, which can provide multiple solutions
according to the requirements of your design and test. IT6860A/B series and
IT6870A/B series programming DC power supply offer the dual-range voltage
switch for your choice, which can replace two ordinary ones.

High-visibility vacuum fluorescent display (VFD)

Digital keypad operation

High accuracy and high resolution

Low ripple and low noise

Intelligent fan control, energy conservation, noise reduction

Can be monitored by computer software

Output voltage and current values accordance with procedure

Can use the knob to adjust the voltage and current

Can adjust the numbers steps using the cursor

Can set the output timer(0.1~9999.9S)

Standard RS232/USB communication interface

Rich SCPI orders and IT6820 compatible frame protocol to facilitate the
formation of intelligent test platform
Model
IT6831A 0~18V
IT6832A 0~32V
IT6833A 0~72V
IT6835A 0~50V
IT6861A 0~20V/ 0~8V
IT6862A 0~32V/ 0~12V
IT6863A 0~72V/ 0~32V
IT6872A 0~35V/0~15V
IT6873A 0~75V/ 0~32V
IT6874A 0~150V/ 0~60V 0~1.2A/ 0~2A 0~180W/ 0~120W
IT6832B 0~32V
IT6833B 0~32V
IT6835B 0~50V
IT6861B 0~20V/ 0~8V
IT6862B 0~32V/ 0~12V
IT6863B 0~72V/ 0~32V
IT6872B 0~35V/ 0~15V
IT6873B 0~75V/ 0~32V
IT6874B 0~150V/ 0~60V 0~1.2A/ 0~2A 0~180W/ 0~120W

Chapter2 Quick Start

Voltage Current
0~10A
0~6A
0~3A
0~4A
0~5A/ 0~9A
0~3A/ 0~6A
0~1.5A/ 0~3A 0~108W/ 0~96W
0~4A/0~7A
0~2A/ 0~4A
0~6A
0~6A
0~4A
0~5A/ 0~9A
0~3A/ 0~6A
0~1.5A/ 0~3A 0~108W/ 0~96W
0~4A/ 0~7A
0~2A/ 0~4A
