Bailey Approach Autograph Series Owner's Manual page 77

Gas Heating
The gas burner has two stages and will shift
dynamically between low or full flame. There
are times when it may use no power at all, even
if gas heating is selected.
1. Press the Flame button to select gas
heating. Green is on, blue is off.
Use both gas and electric heating simultaneously
for best performance.
Climate Control
The AC button is displayed when a Truma
Aventa Comfort air-conditioning
connected to the Alde control panel. This allows
fully automatic climate control, with the heating
and air-conditioning working in unison.
3. Set the desired room temperature as
normal.
4. Press the AC button. Green is on, blue is
off. The heating and air-conditioning will
actively maintain the room temperature.
Alde recommends using the 3020-346 discrete
room temperature sensor for accurate climate
control. It should be located where the
heating and air-con have a balanced effect on
temperature.
Shutting Down the System
To save energy, the control panel only updates
the boiler after the last adjustment is made.
Wait 10 secs before shutting down the system
to ensure the boiler is updated.
1. Press the Power button. The screen goes
dark, the green LED is unlit. The system is
off.
Setup
How you set up your system will depend on
what accessories are installed and your user
preferences. To get you started, here's how to
setup some of the more common features.
Restore default factory settings
Before using the system for the first time,
restore default factory settings. Your control
panel may have been tested by the dealer or
installer, and some settings may have been
changed unintentionally.
1. Press Tool button to access the Settings
Menu (bottom right in Main Menu).
2. Press down arrow, until Reset button is
displayed.
3. Press the Reset button to proceed.
Setup 12V circulation pump in expansion tank
unit is
To use the 12V circulation pump in the expansion
tank, you must set it up. This is not a default
factory setting. NB: This only applies if you have
the 12V circulation pump in the expansion tank.
1. Press Tool button to access the Settings
Menu (bottom right in Main Menu).
2. Press
Accessories button is displayed.
3. Press the Installed Accessories button to
access the menu. Find and tick "Optional
Pump" by pressing the box. Next, find and
untick "Main Manual 12V".
Setup Standby Screen for Bedtime
The backlight on the Standby Screen can be
disturbing if the control panel is visible from
your bed. It can be inverted for white text on
black background.
1. Press Tool button to access the Settings
Menu (bottom right in Main Menu).
2. Press down arrow, until Backlight button is
displayed.
3. Press Backlight button, select Invert to
proceed.
>
down arrow, until
> >
>
75
Installed
