Bracket Installation

1. Connect brackets a & b by placing the
threaded lugs provided through both
section slots (b), into the holes of section
a. Secure with nuts provided.
2. The Otone speaker bracket assembly sits
between the back face of the TV and the
TV wall bracket.
3. Attach to the back of the TV using the
four bolts provided.
4. Loosen nuts to adjust the Otone shelf
section (b) to the correct size for fitting
the Otone speaker.
5. To integrate the speaker with the media
system, insert the right angled AUX plug
though the slot in the bottom of the shelf
section and connect to the Otone speaker.
The spare straight lead should be
connected to the headphone output on
your TV.
Please Note: The AUX plug behind located
behind your front TV should also be plugged
into the headphone output. This can be found
on the side of the TV.
