Architectural
Installation
Topics covered in this section are:
•
•

Installation Instructions

Two versions of the MP 101 series, the MP 101 AAP and MP 101 D, can be mounted into
furniture, a wall, or a floor box. Unless otherwise noted, both units (the MP 101 AAP and the
MP 101 D) are referred to as the "MP 101" in the following instructions.
ATTENTION:

Preparing the Site and Installing the Wall Box

Choose a location that allows cable runs without interference. Allow enough depth for both
the wall box and the cables.
You may need to install the cables into the wall, furniture, or conduits before installing the
mic driver.
•
•
The installation must conform to national and local electrical codes and to the MP 101
size requirements. Dimensional drawings and a template for the MP 101 D are provided in
appendix B of this manual.
1.
Installation Instructions
Preparing the Site and Installing the Wall Box
• The MP 101 must be installed into an Underwriters Laboratories (UL) approved
electrical wall box. The box is not included with the MP 101; the installer is
responsible for obtaining and installing the box.
• Le MP 101 doit être installé dans un boîtier mural électrique homologué UL
(Underwriters Laboratories). Le boîtier n'est pas fourni avec le MP 101 ; il incombe à
l'installeur d'obtenir et d'installer le boîtier.
The MP 101 AAP can be installed into an HSA 400 Series surface access enclosure,
or into a two-gang or four-gang wall box. Its faceplate accepts up to four single height
Extron Architectural Adapter Plates (AAPs).
The MP 101 D can be installed into a standard or compact one-gang electrical wall box
using the included Decorator-style wallplate.
For the MP 101 D only, see the
the MP 101 AAP.
NOTE: The template is not shown at full size. Pay attention to the measurements
shown on the template.
Template on page 19. A template is not required for
MP 101 Series • Architectural Installation 15
