Adjusting the MP 101 AAP

Most adjustment options for the MP 101 AAP are located on its rear panel (see
Series Rear Panels
to final mounting into a wall or a piece of furniture.
To adjust the MP 101 AAP, do the following:
1.
2.
3.
4.

Mounting the MP 101 AAP

The MP 101 AAP must be attached to a device faceplate or AAP wallplate and then cabled
before you can test and perform the final mount (installation into a wall or piece of furniture).
NOTE:
To mount the MP 101 AAP into a device faceplate or AAP wallplate, do the following:
1.
2.
3.
on page 2). Therefore, you must perform these adjustments prior
If using a condenser microphone, flip the Phantom power switch to the ON position.
If using a dynamic microphone, flip the Phantom power switch to the OFF position.
When using the microphone for voice audio, flip the Low Cut switch to ON to reduce
wind and "table rumble" noise.
When using the microphone for music audio, flip the Low Cut switch to OFF to
preserve the optimum sound quality.
Set the Mic Gain potentiometer by saying a few words into the microphone and
adjusting for the maximum sound level that is free of distortion.
If there is a remote control connection, unplug it while adjusting the Mic
NOTE:
Gain potentiometer. Replace the remote control when finished.
If there is minimal distortion, but greater volume is required, turn the Mic Gain
potentiometer clockwise (towards the 75 dB mark) to increase the volume, but not past
the point where distortion occurs.
Before mounting, the MP 101 AAP should be tested to verify that its
connections and settings are correct.
Before any cables are attached, insert the MP 101 AAP standoffs through the holes in
the device faceplate or AAP wallplate.
Secure all cables and connections into the rear connectors of the MP 101 AAP.
Using the provided #4-40 nuts and captive washers, secure the preamplifier to the
faceplate or wallplate, as shown below.
MP 101
