- Page 1 HW Owner’s Manual BILLY GOAT HIGH WHEEL MOWER Owner's Manual HW651SP & HW651HSP Accessories Grass Catcher Kit Easily convert your mower to bag grass and leaves. P/N 510223 Part No 510267 Form No F052808A...
-
Page 2: Table Of Contents
ABOUT THIS MANUAL THANK YOU for purchasing a BILLY GOAT and manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your machine in top running order. Read this manual carefully before assembling, operating, or servicing your equipment. -
Page 3: Serial Plate Data And Specifications
Kawasaki OHV 2.1 qt (2.0 L) 0.63 qt. (0.6 L) 156# (70.8 kg) 62”(1.57m) 32”(0.81m) 43”(1.09m) 100.48dBa 80.48dBa 2.57g HW651HSP 6.5 (4.85 kW) GSV190 HONDA OHV 1.6 qt (1.5 L) 0.69 qt (0.65L) 156# (70.8 kg) 62”(1.57m) 32”(0.81m) 43”(1.09m) 100.48dBa 80.48dBa... -
Page 4: General Safety Instructions And Symbols
This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. This symbol indicates important information that will prevent damage to your BILLY GOAT HW Mower. This symbol indicates the engine oil level should be checked before operating this equipment. - Page 5 DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling. DO NOT store gasoline near an open flame. DO NOT remove gas cap while engine is running.
-
Page 6: Vibration Data
SOUND Sound tests were conducted in accordance with 2000/14/EEC, and were performed on 2-21-2002 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model. -
Page 7: Throttle Controls
INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown. -
Page 8: Parts Bag
PACKING CHECKLIST Your Billy Goat HW Mower is shipped from the factory in one carton, completely assembled except for the upper handle. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box the Handle Assembly is attached and... -
Page 9: Operation
OPERATION Like all mechanical tools, reasonable care must be used when operating machine. Inspect machine work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. PUT OIL IN ENGINE BEFORE STARTING Do not operate if excessive vibration occurs. - Page 10 PROPULSION This unit is self-propelled, and is controlled by a lever control. To engage the wheel drive, pull up and squeeze it against operator's handle. The drive is disengaged by releasing this lever.(See Fig. 3 & 3.1) GROUND SPEED can be varied by selecting a higher or lower gear using the gearshift lever on top of the handle (See Fig.
-
Page 11: Maintenance
Use only original equipment belts for replacement. Billy Goat uses only premium quality, Kevlar corded and coated belts in your unit. Substitute belts do not meet the design and performance requirements for your unit, and will greatly reduce machine performance and belt life. -
Page 12: Drive Belt
BELT REPLACEMENT continued Drive Belt Tools required: 3/8 inch socket, 1/2 inch socket, 3/8" torque wrench. 1. Follow steps 1 through 5 above to remove the blade drive belt. 2. Set the unit on its side to allow access to both pulley and the blade. Note: When tipping the unit on its side, keep the air cleaner side of engine up. -
Page 13: Warranty Claim Procedure
• The machine must be taken to the dealer from whom it was purchased or to an authorized Servicing BILLY GOAT Dealer. • The owner must present the remaining half of the Warranty Registration Card, or, if this is not available, the invoice or receipt. -
Page 14: Illustrated Parts & Parts Lists
PARTS DRAWING HW Part No 510267 HW Owner’s Manual TO TRANS SHIFT LEVER TO DRIVE CLUTCH 69 86 28 29 TO ENGINE BRAKE/ KILL SWITCH Form No F052808A... -
Page 15: Parts List
8143001 8177020 8171004 8171003 510180 8177012 520087 500176 520045 8041030 9201087 8041007 8172007 510255 890301 890254 810736 510169 8161042 HW651HSP PART NO. 510147 510207 510206 400424 830502 900327 400217 8024040 9201072 9201113 350155 8160001 8160003 8160002 8160007 8195166 8059136 500144... -
Page 16: Maintenance Record
HW Owner’s Manual MAINTENANCE RECORD Date Service Performed Part No 510267 Form No F052808A...
