1
Accessories
2
Mulching Kit
P/N 520144
Reduces lawn clippings to fi ne nutri-
ent-rich particles that fi lter down to the
soil.
Grass Catcher Kit
P/N 520142
Easily convert your mower to bag
grass and leaves.
Transaxle Guard Kit
P/N 520155
To protect the transaxle from acci-
dental contact from concrete curbs or
other hazards.
FM3300IN ,FM3300INE, FM3300INB ,FM3300INEB
3
Engine: HP
Engine:Type
Engine: Fuel cap.
Engine: Oil Cap.
Weight: Unit
Weight: Shipping
Part No. 520166
T h a n k Y o u f o r S e l e c t i n g
The Powerful Self-Propelled Billy Goat Mower
Operator Owner's Manual
Specifi cations
FM3300IN
FM3300INE
13.0 HP (9.7 kW)
13.0 HP (9.7 kW)
B&S INTEK OHV
B&S INTEK OHV
with electric start
3.0 qt. (2.8 L)
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
1.5 qt. (1.4 L)
264 # (120 Kg)
274 # (124 Kg)
413 # (187 Kq)
423 # (192 Kq)
UNIT SIZE:
OVERALL LENGTH - 57"(1.45 m)
OVERALL WIDTH - 43" (1.09 m)
OVERALL HEIGHT - 47" (1.19 m)
FM3300INB
13.0 HP (9.7 kW)
B&S INTEK OHV
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
267 # (121 Kg)
417 # (189 Kq)
Page 1 of 20
FM3300INEB
13.0 HP (9.7 kW)
B&S INTEK OHV
with electric start
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
277 # (126 Kg)
427 # (194 Kq)
Form No. F112003A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Billy Goat FM3300IN, FM3300INE
Summary of Contents for Billy Goat FM3300IN, FM3300INE
- Page 1 Transaxle Guard Kit P/N 520155 To protect the transaxle from acci- dental contact from concrete curbs or other hazards. The Powerful Self-Propelled Billy Goat Mower Operator Owner's Manual FM3300IN ,FM3300INE, FM3300INB ,FM3300INEB FM3300IN Engine: HP 13.0 HP (9.7 kW) Engine:Type B&S INTEK OHV...
-
Page 2: Table Of Contents
IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: to the State of California to cause cancer, birth defects or other reproductive harm. WARNING: DO NOT 1. -
Page 3: General Safety
GENERAL SAFETY For your safety and the safety of others, these directions should be followed: Do not operate this machine without fi rst reading owner's manual and engine manufacturer's manual. Use of Ear Protection is recommended while operating this machine. Use of Eye and Breathing protection is recom- mended when using this machine. -
Page 4: Assembly
PUT OIL IN ENGINE BEFORE STARTING. DISCONNECT SPARK PLUG WIRE BEFORE ASSEMBLING UNIT. Your Billy Goat Mower is shipped from the factory in one crate, completely assembled except for the handles and console assembly. NOTE: All item numbers called out in the assembly, operation, and maintenance sections of this manual can be found on Parts List (pages 15-18). -
Page 5: Engine Labels
LITERATURE ASSY Literature Checklist Check Owner's Manual 520166 900407 Ty Wrap Qty 4 CONTROLS Throttle Control ENGINE LABELS Briggs & Stratton Part No. 520166 P/N 520165 33" TRIPLE BLADE ELECTRIC START MODEL Check Check Warranty Card 400972 33" TRIPLE BLADE 33"... -
Page 6: Instruction Labels
INSTRUCTION LABELS These labels should be included on your Billy Goat Finish Mower. If any of these labels are damaged, replace them before putting this equipment into operation. Item and part numbers are given to help in ordering replacement labels.. -
Page 7: Operation
OPERATION INTENDED USE: This unit is mainly designed for cutting grass. Some overgrown weeds, and taller grass may also be cut. Be sure to inspect work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. Like all mechanical tools, reasonable care must be used when operating machine. -
Page 8: Cutting Height Adjustment
OPERATION continued 16.3 CUTTING HEIGHT ADJUSTMENT CAUTION: DO NOT make cutting height adjustment when engine is running. Cutting height can be adjusted from 1.0" to 3.5" by placing spacers above or below caster spindles. For easiest adjust- ment change the height on one side at a time. To change cutting height, tilt the unit back, remove lynch pin, remove all spacers then set if off to the side, remove caster rig, add or subtract spacers, reinstall caster rig, place remainder... - Page 9 OPERATION continued PROPULSION 16.5 This unit is self-propelled, and is controlled by an operator presence control. To engage the wheel drive, first push down on the BRAKE RELEASE lever on the right side, then lift the operator's DRIVE lever on the right side against operator's handle.
-
Page 10: Maintenance
MAINTENANCE Note: Blade, blade brake puck, transaxle brake, and drive belts are normal wear items. These should be inspected on a regular basis and replaced if worn. MAINTENANCE HISTORY Date of Service Service Performed ADJUST ALL BELT TENSIONS AFTER FIRST 5 HRS. OF USE TO PROLONG THE LIFE OF BELTS. Maintenance Schedule Maintenance Operation Engine (See Engine Manual) -
Page 11: Cable Adjustments
MAINTENANCE continued 17.1 CABLE ADJUSTMENTS CAUTION: DO NOT make cable adjustment when engine is running. Disconnect spark plug wire before making any adjustments. Brake Adjustment The brake control cable is spring loaded and requires no adjustment; however, the transaxle brake is adjustable. When the mower is in neutral and can be pushed by hand without depressing the brake lever, the transaxle brake needs adjustment. -
Page 12: Blade Removal / Sharpening
It is good practice to change both belts when either is worn beyond use. Use only original equipment belts for replacement. Billy Goat uses only premium quality, kevlar corded and coated belts in your unit. -
Page 13: Spindle Drive Belt
MAINTENANCE continued BELT REPLACEMENT continued 17.5 Blade Drive Belt Replacement 13. Reinstall the left and right belt guide fi ngers under the engine base using all fasteners in the exact order they were removed. NOTE: Before installing the fasteners inspect them for wear and replace as necessary. -
Page 14: Brake Puck Replacement
MAINTENANCE BRAKE PUCK REPLACEMENT 17.6 Tools Required: 5/32” Allen wrench; 3/8” wrench. 1. Remove the spark plug wire. 2. Remove the belt deck cover. 3. Remove the brake spring (A) and control cable spring (B) (see fi gure 17-10). 4. Remove the blade drive belt (C) from the drive pulley (D). 5. -
Page 15: Deck Assembly
ITEM DESCRIPTION FM3300INE QTY FM3300INEB BUSHING PIVOT 360183 LABEL DANGER FLY 810736 LABEL WARNING 400424 LABEL HGT. GUIDELINE 520043 SPRING EXHAUST CHUTE 510205 LABEL WARNING MOWER 510206 BLADE 11.88” 520001 LYNCH PIN 3/16” X 1 9/16 520004 WHEEL AND TIRE 8” ASSY. 520005 BELT SPINDLE DRIVE 520007... -
Page 16: Engine Assembly
Battery is not included ITEM DESCRIPTION FM3300INE QTY FM3300INEB LABEL DO NOT FILL HOT 400268 WASHER 3/8” TWISTED LOCK 400502 WASHER 5/16" TWISTED LK. 430298 BOX BATTERY ASSY 500300 SCREW SOCKET #10 X 1” 520018 BOLT SHOULDER 1/2” X 2” 520031 IDLER PLASTIC 4”... -
Page 17: Drive Assembly
BELT LAYOUT ENGINE PULLEY BLADE CLUTCH IDLER PULLEY SPINDLE PULLEY DECK DRIVE PULLEY ITEM DESCRIPTION FM3300INE QTY FM3300INEB BELT TRANS DRIVE FM 520003 BELT BLADE DRIVE FM 520006 SPRING TORSION WIRE 520009 TRANSAXLE 5SPD FM 520010 BRACKET T-AXLE SUPPORT 520016 BOLT SHOULDER 1/2”... -
Page 18: Handle Assembly
ITEM DESCRIPTION FM3300INE QTY FM3300INEB PALNUTS 3/8” 360218 KNOB 1/2” THREAD 430128 LABEL CLUTCH DRIVE 500176 LABEL BLADE DRIVE 500177 GRIP HANDLE 1” x 7” 500267 SWITCH ELECTRIC W/ NUT 500307 SPRING COMPRESSOR 1/2” 520017 CONTROL THROTTLE POS 520019 ROD SHIFT LINKGAGE 520020 BAR HANDLE BRACE FM 520024... -
Page 19: Mulching Kit
ACCESSORIES GRASS CATCHER KIT 520144 19.1 Purpose: Easily convert your mower to bag grass and leaves. Item No. MULCHING KIT 520142 19.2 Purpose: Reduces lawn clippings to fi ne nutrient-rich particles that fi lter down to the soil. Item No. Part No. -
Page 20: Troubleshooting
Before Requesting Service Review These Suggestions Possible Cause Should a Billy Goat Machine fail due to a defect in material and / or workmanship, the owner should make a warranty claim as follows: -The Machine must be taken to the dealer from whom it was purchased or to an authorized Servicing Billy Goat Dealer. - Page 21 Gardening Supply Patio Barbecues Outdoor Barbecues Charcoal Barbecues Gas Barbecues Brush Cutters Brushcutters Chainsaws Cultivators Echo Strimmers Electric Chainsaws Garden Rollers Lawn Rollers Garden Vacuums Hayter Lawn Mowers Hover Mowers Husqvarna chainsaws Lawn Mowers Scarifiers Leaf Vacuums Petrol Chainsaws Ride on mowers Rotary Mowers Electric Garden Petrol Garden...
