HP MOWER Owner's Manual
BILLY GOAT HOMEPRO 34" MOWER
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE
Part No 521316
Owner's Manual
HP3401
Beginning Serial #: 110215001
Accessories
Mulching Kit
Reduces lawn
clippings to fine
nutrient-rich
particles that filter
down to the soil.
P/N 521400
Original Instructions
Grass Catcher Kit
Easily convert your
mower to bag
grass and leaves.
P/N 521401
1
Form No F110315A
Advertisement
Table of Contents
Related Manuals for Billy Goat HOMEPRO HP3401
Summary of Contents for Billy Goat HOMEPRO HP3401
- Page 1 HP MOWER Owner’s Manual BILLY GOAT HOMEPRO 34" MOWER Owner's Manual HP3401 Beginning Serial #: 110215001 Accessories Mulching Kit Grass Catcher Kit Reduces lawn Easily convert your clippings to fine mower to bag nutrient-rich grass and leaves. particles that filter down to the soil.
- Page 2 HP MOWER Owner’s Manual CONTENTS SPECIFICATIONS AND SOUND/VIBRATION INSTRUCTION LABELS PACKING CHECKLIST & ASSEMBLY _______ OPERATION MAINTENANCE AND TROUBLESHOOTING 8-10 ILLUSTRATED PARTS & PARTS LISTS 11-18 Go to http://www.billygoat.com for translations of the product manuals. Visitez http://www.billygoat.com pour la version canadienne-française des manuels de produits Part No 521316 Form No F110315A...
-
Page 3: Specifications
HP MOWER Owner’s Manual SPECIFICATIONS HP3401 Engine: cc's 344cc Engine: Model 2158020167B1 Engine: Type B & S Intek Engine: Fuel Capacity 2.8 qt. (2.65 L) Engine: Oil Capacity 1.5 qt. (1.4 L) Total Unit Weight: 238# (108 Kg) Max. operating slope Overall length 68”... -
Page 4: Instruction Labels
INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT HP Mower. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown. -
Page 5: Packing Checklist
HP MOWER Owner’s Manual PACKING CHECKLIST Your Billy Goat Mower is shipped from the factory in one crate, completely assembled except for the handles and controls. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box. -
Page 6: Cutting Operation
HP MOWER Owner’s Manual OPERATION CAUTION: Wheels must be chocked or blocked when unit is parked on a slope. CUTTING OPERATION CAUTION: Shut off the blades when crossing gravel drives, walks or roads and under all conditions where thrown objects might be a hazard. CLEARING A CLOGGED CUTTING DECK: Turn engine off and wait for blade to stop completely. - Page 7 HP MOWER Owner’s Manual Blade Clutch Lever BLADE CLUTCH The HP mower blade clutch is controlled by an operator presence control. To engage the blade, depress the operator’s left hand control lever against operator’s handle. The blades are disengaged by releasing this lever. (See figure 16-5) NOTE: The blade clutch must be either fully engaged for cutting or fully disengaged to bring the blades to a stop.
-
Page 8: Periodic Maintenance
Note: Blade, and drive belts are normal wear items. These should be inspected on a regular basis and replaced if worn. Also see your Billy Goat Dealer for servicing your machine. BLADE Removal / Sharpening NOTE: When sharpening the blade it is a good idea to check the balance of the blade. -
Page 9: Belt Replacement
Use only original equipment belts for replacement. Billy Goat uses only premium quality, Kevlar corded and coated belts in your unit. Substitute belts do not meet the design and performance requirements for your unit, and will greatly reduce machine performance and belt life. -
Page 10: Cable Adjustments
HP MOWER Owner’s Manual CABLE ADJUSTMENTS Transaxle Drive Control Cable Adjustment When the transaxle drive belt slips, the drive control cable needs to be adjusted or the belt needs to be replaced with a new belt. Cable Adjustment: 2. Using a ½ “ open end wrench, turn the inside adjusting nut counter-clockwise and back it off 1/8", then tighten the outboard adjusting nut against the support bracket (see figure 17-2). - Page 11 HP MOWER Owner’s Manual PARTS DRAWING ENGINE Part No 521316 Form No F110315A...
-
Page 12: Parts List Engine
HP MOWER Owner’s Manual PARTS LIST ENGINE Item No. Part Number Description 521146 Base Engine WA HP3401 830223 Belt 4L x 34 521112 Belt 5l x 60 521105 Engine 10.5 HP Intek 521317 Clutch HP 521212 Idler Arm WA 521121 Pulley idler arm HP 521320 Bracket Anti-Rotation... - Page 13 HP MOWER Owner’s Manual PARTS DRAWING DECK Part No 521316 Form No F110315A...
- Page 14 HP MOWER Owner’s Manual PARTS LIST DECK Item No. Part Number Description 521209 Deck WA HP 521210 Caster Arm WA HP 520184 Bushing Flange 1" OD 3/4" ID 521211 Caster Bracket WA HP 521112 Belt 5l x 60 521101 Spindle Assy w/Pulley 521109 Blade 17.25"...
- Page 15 HP MOWER Owner’s Manual PARTS DRAWING HANDLE Part No 521316 Form No F110315A...
-
Page 16: Parts List Handle
HP MOWER Owner’s Manual PARTS LIST HANDLE Item No. Part Number Description 521300 Label Logo HP 521301 Label Instruction HP 521214 Handle Lower HP 521216 Handle Upper LH HP 521215 Handle Upper RH HP 521104 Lever Control Drive HP 500267 Grip Handle 521222 Console WA HP... - Page 17 HP MOWER Owner’s Manual PARTS DRAWING TRANSMISSION Part No 521316 Form No F110315A...
- Page 18 HP MOWER Owner’s Manual PARTS LIST TRANSMISSION Item No. Part Number Description 521102 Transaxle HP 521103 Wheel 13" x 6.50 Pneu. SP 521122 Belt 4L x 33 521120 Bar Shift HP 521119 Pulley 5" x 5/8 ID 521318 Bracket Mount Clutch Cable 521135 Bar Brace Transmission 8171003...
