Billy goat powerful self-propelled mower owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

1
Accessories
2
Mulching Kit
P/N 520144
Reduces lawn clippings to fi ne nutrient-rich par-
ticles that fi lter down to the soil.
Grass Catcher Kit
P/N 520142
Easily convert your mower to bag grass and leaves.
Transaxle Guard Kit
P/N 520155
To protect the transaxle from accidental contact
from concrete curbs or other hazards.
Part No. 520188
T h a n k Y o u f o r S e l e c t i n g
The Powerful Self-Propelled Billy Goat Mower
Operator Owner's Manual
FM3301IN & FM3301INE
Patent Number:
3
Engine: HP
Engine:Type
Engine: Fuel cap.
Engine: Oil Cap.
Weight: Unit
Weight: Shipping
D494985
Specifi cations
FM3301IN
13.0 HP (9.7 kW)
B&S INTEK OHV
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
267 # (121 Kg)
343# (156Kq)
UNIT SIZE:
OVERALL LENGTH - 57"(1.44 m)
OVERALL WIDTH - 43" (1.09 m)
OVERALL HEIGHT - 47" (1.19 m)
Page 1 of 20
FM3301INE
13.0 HP (9.7 kW)
B&S INTEK OHV
ELECTRIC START
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
277 # (126 Kg)
353# (160Kq)
Form No. F110404B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM3301IN, FM3301INE and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat FM3301IN, FM3301INE

Summary of Contents for Billy Goat FM3301IN, FM3301INE

  • Page 1 T h a n k Y o u f o r S e l e c t i n g The Powerful Self-Propelled Billy Goat Mower Operator Owner's Manual Accessories Mulching Kit P/N 520144 Reduces lawn clippings to fi ne nutrient-rich par- ticles that fi...

  • Page 2: In The Interest Of Safety

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: to the State of California to cause cancer, birth defects or other reproductive harm. WARNING: DO NOT 1.

  • Page 3: General Safety

    GENERAL SAFETY For your safety and the safety of others, these directions should be followed: Do not operate this machine without fi rst reading owner's manual and engine manufacturer's manual. Use of Ear Protection is recommended while operating this machine. Use of Eye and Breathing protection is recom- mended when using this machine.
  • Page 4 PUT OIL IN ENGINE BEFORE STARTING. DISCONNECT SPARK PLUG WIRE BEFORE ASSEMBLING UNIT. Your Billy Goat Mower is shipped from the factory in one crate, completely assembled except for the handles and console assembly. NOTE: All item numbers called out in the assembly, operation, and maintenance sections of this manual can be found on Parts List (pages 15-18).

  • Page 5: Engine Labels

    LITERATURE ASSY Check Owner's Manual 520188 900407 Ty Wrap Qty 4 8041051 Screwcap 3/8" x 1.25" Qty 4 CONTROLS Throttle Control ENGINE LABELS Part No. 520188 P/N 520165 Literature Checklist Check Check Warranty Declaration Card of Conformity 400972 33" TRIPLE BLADE ELECTRIC START MODEL 520119 Clevis Pin...

  • Page 6: Instruction Labels

    INSTRUCTION LABELS These labels should be included on your Billy Goat Finish Mower. If any of these labels are damaged, replace them before putting this equipment into operation. Item and part numbers are given to help in ordering replacement labels..

  • Page 7: Cutting Operation

    OPERATION INTENDED USE: This unit is mainly designed for cutting grass. Some overgrown weeds, and taller grass may also be cut. Be sure to inspect work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. Like all mechanical tools, reasonable care must be used when operating machine.

  • Page 8: Cutting Height Adjustment

    OPERATION continued 16.3 CUTTING HEIGHT ADJUSTMENT CAUTION: DO NOT make cutting height adjustment when engine is running. Cutting height can be adjusted from 1.0" to 3.5" by placing spacers above or below caster spindles. For easiest adjust- ment change the height on one side at a time. To change cutting height, tilt the unit back, remove lynch pin, remove all spacers then set if off to the side, remove caster rig, add or subtract spacers, reinstall caster rig, place remainder...
  • Page 9 OPERATION continued PROPULSION 16.5 This unit is self-propelled, and is controlled by an operator presence control. To engage the wheel drive, first push down on the BRAKE RELEASE lever on the right side, then lift the operator's DRIVE lever on the right side against operator's handle.

  • Page 10: Maintenance

    MAINTENANCE Use only a qualifi ed mechanic for any adjustments, disassembly or any kind of repair . WARNING: TO AVOID PERSONAL INJURY, ALWAYS TURN MACHINE OFF, MAKE SURE ALL MOVING PARTS COME TO A COM- PLETE STOP. WARNING: FOLLOWING ENGINE OIL CHANGE BE SURE OIL DRAIN VALVE IS CLOSE &...

  • Page 11: Cable Adjustments

    MAINTENANCE continued 17.1 CABLE ADJUSTMENTS CAUTION: DO NOT make cable adjustment when engine is running. Disconnect spark plug wire before making any adjustments. Brake Adjustment The brake control cable is spring loaded and requires no adjustment; however, the transaxle brake is adjustable. When the mower is in neutral and can be pushed by hand without depressing the brake lever, the transaxle brake needs adjustment.

  • Page 12: Blade Removal / Sharpening

    It is good practice to change both belts when either is worn beyond use. Use only original equipment belts for replacement. Billy Goat uses only premium quality, kevlar corded and coated belts in your unit.
  • Page 13 MAINTENANCE continued BELT REPLACEMENT continued 17.5 Blade Drive Belt Replacement 15. Observe the idler pulley when the blade drive lever is lowered and released (see fi gure 17-7). NOTE: Idler should tighten the belt when blade drive lever is pressed and the belt should be slack when the lever is released.

  • Page 14: Brake Puck Replacement

    MAINTENANCE BRAKE PUCK REPLACEMENT 17.6 Tools Required: 5/32” Allen wrench; 3/8” wrench. 1. Remove the spark plug wire. 2. Remove the belt deck cover. 3. Remove the brake spring (A) and control cable spring (B) (see fi gure 17-10). 4. Remove the blade drive belt (C) from the drive pulley (D). 5.

  • Page 15: Parts Drawing

    ITEM DESCRIPTION FM3301INE PART NO. BUSHING BRONZE 520184 LABEL DANGER FLY 810736 LABEL WARNING 400424 LABEL HGT. GUIDELINE 520159 SPRING EXHAUST CHUTE 510205 LABEL WARNING MOWER 510206 BLADE 11.88” 520001 LYNCH PIN 3/16” X 1 9/16 520004 WHEEL AND TIRE 8” ASSY. 520005 BELT SPINDLE DRIVE 520007...
  • Page 16 Battery is not included ITEM DESCRIPTION FM3301INE PART NO. LABEL DO NOT FILL HOT 400268 WASHER SPLIT LOCK 3/8" 8177012 4 WASHER 5/16" TWISTED LK. 430298 BOX BATTERY ASSY 500300 SCREW SOCKET #10 X 1” 520018 BOLT SHOULDER 1/2” X 2” 520031 IDLER PLASTIC 4”...
  • Page 17 BELT LAYOUT ENGINE PULLEY BLADE CLUTCH IDLER PULLEY SPINDLE PULLEY DECK DRIVE PULLEY ITEM DESCRIPTION FM3301INE PART NO. BELT TRANS DRIVE FM 520003 BELT BLADE DRIVE FM 520006 SPRING TORSION WIRE 520009 TRANSAXLE 5SPD FM 520010 BRACKET T-AXLE SUPPORT 520016 BOLT SHOULDER 1/2”...
  • Page 18 ITEM DESCRIPTION FM3301INE PART NO. PALNUTS 3/8” 360218 KNOB 1/2” THREAD 430128 LABEL CLUTCH DRIVE 500176 LABEL BLADE DRIVE 500177 GRIP HANDLE 1” x 7” 500267 SWITCH ELECTRIC W/ NUT 500307 SPRING COMPRESSOR 1/2” 520017 CONTROL THROTTLE POS 520019 ROD SHIFT LINKGAGE 520179 BAR HANDLE BRACE FM 520024...

  • Page 19: Mulching Kit

    ACCESSORIES GRASS CATCHER KIT 520142 19.1 Purpose: Easily convert your mower to bag grass and leaves. Item No. MULCHING KIT 520144 19.2 Purpose: Reduces lawn clippings to fi ne nutrient-rich particles that fi lter down to the soil. Item No. Part No.

  • Page 20: Troubleshooting

    Before Requesting Service Review These Suggestions Possible Cause Should a Billy Goat Machine fail due to a defect in material and / or workmanship, the owner should make a warranty claim as follows: -The Machine must be taken to the dealer from whom it was purchased or to an authorized Servicing Billy Goat Dealer.
