1
Operator Owner's Manual
Accessories
2
Mulching Kit
P/N 510202
Reduces lawn clippings to fi ne
nutrient-rich particles that fi lter
down to the soil.
Grass Catcher Kit
P/N 510223
Easily convert your mower to bag
grass and leaves.
Part No. 510153
T h a n k Y o u f o r S e l e c t i n g
The Powerful Self-Propelled High Wheel Mower
Patent Pending
3
HW650SP
Specifi cations
HW650SP
Engine: HP
Engine:Type
Engine: Fuel cap.
Engine: Oil Cap.
Weight: Unit
Weight: Shipping
UNIT SIZE:
OVERALL LENGTH - 82.5"(2.09 m)
OVERALL WIDTH - 32.0" (0.81m)
OVERALL HEIGHT - 43" (1.09m)
Page 1 of 12
6.5 HP (4.85 kW)
B&S OHV
1.6 qt. (1.5 L)
0.63 qt. (0.6 L)
154 # (70.0 Kg)
167 # (77.7 Kq)
Form No. F102802D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HW650SP and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat HW650SP

Summary of Contents for Billy Goat HW650SP

  • Page 1 fi lter down to the soil. Grass Catcher Kit P/N 510223 Easily convert your mower to bag grass and leaves. Part No. 510153 HW650SP Patent Pending Specifi cations HW650SP Engine: HP Engine:Type Engine: Fuel cap. Engine: Oil Cap.

  • Page 2: Table Of Contents

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: to the State of California to cause cancer, birth defects or other reproductive harm. WARNING: DO NOT 1.

  • Page 3: General Safety

    GENERAL SAFETY For your safety and the safety of others, these directions should be followed: Do not operate this machine without fi rst reading owner's manual and engine manufacturer's manual. Use of Ear Protection is recommended while operating this machine. Use of Eye and Breathing protection is recom- mended when using this machine.

  • Page 4: Engine Labels

    STARTING. DISCONNECT SPARK PLUG WIRE BEFORE ASSEMBLING UNIT. Your Billy Goat High Wheel Mower is shipped from the factory in one carton, completely assembled. INSTRUCTION LABELS These labels should be included on your Contour mower. If any of these labels are damaged, replace them before putting this equipment into operation.

  • Page 5: Operation

    OPERATION INTENDED USE: This unit is mainly designed for cutting grass. Some overgrown weeds, and taller grass may also be cut. Be sure to inspect work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. Like all mechanical tools, reasonable care must be used when operating machine.
  • Page 6 OPERATION continued PROPULSION 16.4 This unit is self-propelled, and is controlled by an operator presence control. To engage the wheel drive, push forward on the bail (back of the handle) and squeeze it against operator's handle. The drive is disengaged by releasing this bail.(See Fig.

  • Page 7: Maintenance

    OPERATION continued 16.5 HILLSIDE MOWING Fig. 5.1 WARNING! Never mow on any slope greater than 15 degrees. Always mow across the face of slopes; never up and down or diagonally see fig 5.1). DO NOT attempt sudden starts or stop when mowing on a slope.

  • Page 8: Blade Removal / Sharpening

    It is good practice to change both belts when either is worn beyond use. Use only original equipment belts for replacement. Billy Goat uses only premium quality, kevlar corded and coated belts in your unit. Substitute belts do not meet the design and performance requirements for your unit , and will greatly reduce machine performance and belt life.
  • Page 9 MAINTENANCE continued BELT REPLACEMENT 17.2 Drive Belt Tools required: 3/8 inch socket, 1/2 inch socket, 3/8" torque wrench. 1. Follow steps 1 through 5 above to remove the blade drive belt. 2. Set the unit on its side to allow access to both pulley and the blade.

  • Page 10: Parts Drawing & List

    Part No. 510153 Page 10 of 12 includes PARTS DRAWING HW650SP Form No. F102802D...
  • Page 11 DECK ASSY W/LABELS PIN 3/8 X 1 1/2 BEARING 3/4 CAST FLANGE BASE ASSY W/LABELS SPRING TRANS IDLER SPRING EXHAUST CHUTE BUSHING LEVER CONTROL Part No. 510153 HW650SP Item Description Part No. 510178 LABEL CUTTING HGT. LABEL INSTRUCTION 510179 510134...

  • Page 12: Troubleshooting

    Before Requesting Service Review These Suggestions Possible Cause Please fi ll in the WARRANTY CARD and send the upper part to Billy Goat. The WARRANTY terms are stated on the lower part which remains with the user. Whenever a Billy Goat Machine is faulty due to a defect in material...
