1
Accessories
2
Mulching Kit
P/N 520144
Reduces lawn clippings to fi ne nutrient-rich par-
ticles that fi lter down to the soil.
Grass Catcher Kit
P/N 520142
Easily convert your mower to bag grass and leaves.
Transaxle Guard Kit
P/N 520155
To protect the transaxle from accidental contact
from concrete curbs or other hazards.
Part No. 520187
T h a n k Y o u f o r S e l e c t i n g
The Powerful Self-Propelled Billy Goat Mower
Operator Owner's Manual
FM3301 & FM3301E
Patent Number:
3
Engine: HP
Engine:Type
Engine: Fuel cap.
Engine: Oil Cap.
Weight: Unit
Weight: Shipping
D494985
Specifi cations
FM3301
13.0 HP (9.7 kW)
B&S INTEK OHV
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
267 # (121 Kg)
343# (156 Kq)
UNIT SIZE:
OVERALL LENGTH - 57"(1.44 m)
OVERALL WIDTH - 43" (1.09 m)
OVERALL HEIGHT - 47" (1.19 m)
Page 1 of 20
FM3301E
13.0 HP (9.7 kW)
B&S INTEK OHV
ELECTRIC START
3.0 qt. (2.8 L)
1.5 qt. (1.4 L)
277 # (126 Kg)
353# (160 Kq)
Form No. F102004A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM3301 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billy Goat FM3301

Summary of Contents for Billy Goat FM3301

  • Page 1 T h a n k Y o u f o r S e l e c t i n g The Powerful Self-Propelled Billy Goat Mower Operator Owner's Manual Accessories Mulching Kit P/N 520144 Reduces lawn clippings to fi ne nutrient-rich par- ticles that fi...

  • Page 2: In The Interest Of Safety

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: to the State of California to cause cancer, birth defects or other reproductive harm. WARNING: DO NOT 1.

  • Page 3: General Safety

    GENERAL SAFETY For your safety and the safety of others, these directions should be followed: Do not operate this machine without fi rst reading owner's manual and engine manufacturer's manual. Use of Ear Protection is recommended while operating this machine. Use of Eye and Breathing protection is recom- mended when using this machine.
  • Page 4 PUT OIL IN ENGINE BEFORE STARTING. DISCONNECT SPARK PLUG WIRE BEFORE ASSEMBLING UNIT. Your Billy Goat Mower is shipped from the factory in one crate, completely assembled except for the handles and console assembly. NOTE: All item numbers called out in the assembly, operation, and maintenance sections of this manual can be found on Parts List (pages 15-18).

  • Page 5: Engine Labels

    LITERATURE ASSY Literature Checklist Check Owner's Owner's Manual Manual 520187 900407 Ty Wrap Qty 4 8041051 Screwcap 3/8" x 1.25" Qty 4 CONTROLS Throttle Control ENGINE LABELS Part No. 520187 P/N 520137 Check Warranty Card 400972 33" TRIPLE BLADE ELECTRIC START MODEL 520119 Clevis Pin Roll Pin 1/4"...

  • Page 6: Instruction Labels

    INSTRUCTION LABELS These labels should be included on your Billy Goat Finish Mower. If any of these labels are damaged, replace them before putting this equipment into operation. Item and part numbers are given to help in ordering replacement labels..

  • Page 7: Cutting Operation

    OPERATION INTENDED USE: This unit is mainly designed for cutting grass. Some overgrown weeds, and taller grass may also be cut. Be sure to inspect work area and machine before operating. Make sure that all operators of this equipment are trained in general machine use and safety. Like all mechanical tools, reasonable care must be used when operating machine.

  • Page 8: Cutting Height Adjustment

    OPERATION continued 16.3 CUTTING HEIGHT ADJUSTMENT CAUTION: DO NOT make cutting height adjustment when engine is running. Cutting height can be adjusted from 1.5" to 4" by placing spacers above or below caster spindles. For easiest adjust- ment change the height on one side at a time. To change cutting height, tilt the unit back, remove lynch pin, remove all spacers then set if off to the side, remove caster rig, add or subtract spacers, reinstall caster rig, place remainder...
  • Page 9 OPERATION continued PROPULSION 16.5 This unit is self-propelled, and is controlled by an operator presence control. To engage the wheel drive, first push down on the BRAKE RELEASE lever on the right side, then lift the operator's DRIVE lever on the right side against operator's handle.

  • Page 10: Maintenance

    MAINTENANCE Use only a qualifi ed mechanic for any adjustments, disassembly or any kind of repair . WARNING: TO AVOID PERSONAL INJURY, ALWAYS TURN MACHINE OFF, MAKE SURE ALL MOVING PARTS COME TO A COM- PLETE STOP. WARNING: FOLLOWING ENGINE OIL CHANGE BE SURE OIL DRAIN VALVE IS CLOSE &...

  • Page 11: Cable Adjustments

    MAINTENANCE continued 17.1 CABLE ADJUSTMENTS CAUTION: DO NOT make cable adjustment when engine is running. Disconnect spark plug wire before making any adjustments. Brake Adjustment The brake control cable is spring loaded and requires no adjustment; however, the transaxle brake is adjustable. When the mower is in neutral and can be pushed by hand without depressing the brake lever, the transaxle brake needs adjustment.

  • Page 12: Blade Removal / Sharpening

    It is good practice to change both belts when either is worn beyond use. Use only original equipment belts for replacement. Billy Goat uses only premium quality, kevlar corded and coated belts in your unit.
  • Page 13 MAINTENANCE continued BELT REPLACEMENT 17.5 continued Blade Drive Belt Replacement 15. Observe the idler pulley when the blade drive lever is lowered and released (see fi gure 17-7). NOTE: Idler should tighten the belt when blade drive lever is pressed and the belt should be slack when the lever is released.

  • Page 14: Brake Puck Replacement

    MAINTENANCE BRAKE PUCK REPLACEMENT 17.6 Tools Required: 5/32” Allen wrench; 3/8” wrench. 1. Remove the spark plug wire. 2. Remove the belt deck cover. 3. Remove the brake spring (A) and control cable spring (B) (see fi gure 17-10). 4. Remove the blade drive belt (C) from the drive pulley (D). 5.

  • Page 15: Parts Drawing

    520081 520088 520100-S 1 520109 610308-P 3 900327 Page 15 of 20 PARTS DRAWING FM3301 & FM3301E DECK ASSEMBLY DESCRIPTION FM3301E QTY PART NO. BOLT CARRIAGE 3/8-16X1” ZP 8024058 5 BOLT CARRIAGE 3/8-X 1 1/4 8024059 SCREW CAP 1/4 - 20 X 7"...
  • Page 16 NUT JAM 5/16" 520114 POSITIVE CABLE 10" WASHER 3/8" FLATCUT WASHER #10 FLATCUT 8041051 4 VALVE OIL DRAIN Page 16 of 20 PARTS DRAWING FM3301 & FM3301E ENGINE ASSEMBLY FM3301E QTY PART NO. 850132 850443 890359 890408 900327 8024039 2...
  • Page 17 850230 NUT JAM 1/4-20 850408 RING SNAP 5/8 T.A. 8024023 1 8024058 2 WASHER 3/4" Page 17 of 20 PARTS DRAWING FM3301 & FM3301E DRIVE ASSEMBLY TO CONSOLE 156 158 FM3301E QTY PART NO. 8041053 1 8041013 1 8041029 1...
  • Page 18 520084-S 1 520085 500130 520091-S 1 520093-S 1 520094 520095 520096 520097 Page 18 of 20 PARTS DRAWING FM3301 & FM3301E HANDLE ASSEMBLY DESCRIPTION FM3301E QTY PART NO. GRIP LEVER ORANGE 520098 CONSOLE FM W/ LABELS 520146 CUP HOLDER 520102...

  • Page 19: Mulching Kit

    ACCESSORIES GRASS CATCHER KIT 520142 19.1 Purpose: Easily convert your mower to bag grass and leaves. Item No. MULCHING KIT 520144 19.2 Purpose: Reduces lawn clippings to fi ne nutrient-rich particles that fi lter down to the soil. Item No. Part No.

  • Page 20: Troubleshooting

    Before Requesting Service Review These Suggestions Possible Cause Should a Billy Goat Machine fail due to a defect in material and / or workmanship, the owner should make a warranty claim as follows: -The Machine must be taken to the dealer from whom it was purchased or to an authorized Servicing Billy Goat Dealer.
