GZ Owner's Manual
BILLY GOAT GRAZOR®
Owner's Manual
GZ401H & GZ451S
Accessories
8" STANDARD
DRIVE BELT
REPLACEMENT
BRUSH
Standard
Original
replacement wire
Equipment Belt
brush.
for replacement.
P/N 610140
P/N 610420
ENGINE
PULLEY
Original
Equipment
Pulley
for replacement.
P/N 610417
1
BRUSH DRIVE
PULLEY
Original
Equipment
Pulley
for replacement.
P/N 610403
Form No F052913A

Advertisement

Table of Contents
loading

Related Manuals for Billy Goat GRAZOR GZ401H

Summary of Contents for Billy Goat GRAZOR GZ401H

  • Page 1 GZ Owner’s Manual BILLY GOAT GRAZOR® Owner's Manual GZ401H & GZ451S Accessories 8" PREMIUM HEAVY 8" STANDARD ENGINE BRUSH DRIVE DRIVE BELT DUTY REPLACEMENT REPLACEMENT PULLEY PULLEY BRUSH BRUSH OEM quality Standard Original Original Original replacement wire replacement wire Equipment Belt...
  • Page 2 GZ Owner’s Manual CONTENTS SPECIFICATIONS _______________________ INSTRUCTION LABELS PACKING CHECKLIST & ASSEMBLY OPERATION MAINTENANCE TROUBLESHOOTING____________________________ ILLUSTRATED PARTS & PARTS LISTS 10-11 Go to http://www.billygoat.com for French-Canadian translations of the product manuals. Visitez http://www.billygoat.com pour la version canadienne-française des manuels de produits Part No 610445 Form No F052913A...

  • Page 3: Specifications

    GZ Owner’s Manual Specifications GZ401H GZ451S Engine: HP 4.0 (2.98 kW) 4.5 (3.36 kW) Engine: Model GX120T1QA2 EX130D50031 Engine: Type HONDA OHV SUBARU OHV Engine: Fuel Capacity 2.1 qt. (2.0 L) 3.0 qt (2.9 L) Engine: Oil Capacity 0.63 qt. (0.6 L) 0.63 qt.

  • Page 4: Instruction Labels

    INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT Grazor. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.

  • Page 5: Packing Checklist

    GZ Owner’s Manual PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton, completely assembled except for the upper handle assembly, lower handles, handle brace, brush lift rod, and brush. READ all safety instructions before assembling unit.

  • Page 6: Operation

    GZ Owner’s Manual OPERATION OPERATION 1. Do not operate product when barefoot or wearing open sandals. Always wear safety footwear, pants or slacks that cover your legs. 2. DO NOT use product on graveled surfaces. 3. Never operate this product without good visibility or light. 4.
  • Page 7 GZ Owner’s Manual Brush usage Recommendations Pressure – Avoid excessive pressure when using a power brush. Excessive pressure causes over-bending of the filaments and heat build-up resulting in filament breakage, rapid dulling and reduced brush life. Instead of greater pressure on a brush, it is suggested that you try: 1) a brush with a more aggressive cutting action (increased wire size, decreased filament length, change to a different brush type, i.e., knot type instead of crimped wire type), or 2) higher speed (increased R.P.M., increased brush diameter.)

  • Page 8: Maintenance

    4. Slide the brush (item 6) sideways off of the bearing shaft. 5. Install new brush over the shaft. NOTE: Be sure that to use the nylon bushing that comes with the Billy Goat replacement brush to insure proper fit between the brush and the shaft.

  • Page 9: Troubleshooting

    GZ Owner’s Manual Troubleshooting Problem Possible Cause Solution Engine will not start. Stop switch of. Throttle in off position. Engine Check stop switches, throttle, choke not in full choke position. Out of gasoline. Bad position and gasoline. Connect spark or old gasoline. Spark plug wire disconnected. plug wire.
  • Page 10 GZ Owner’s Manual PARTS DRAWING GZ Part No 610445 Form No F052913A...

  • Page 11: Parts List

    GZ Owner’s Manual PARTS LIST PARTS item GZ401H GZ451S LIST Part No. Part No. Bushing Pivot Frame 360183 360183 Label Hot Engine EN/SP 100261 Grip Handle 1" X 13" 400570 400570 Screw self tap 1/4-20 x 5/8 type F 890359 890359 Label Danger 600117...
