Application Examples
Program the frequency converter as in Table 7.2:
Parameter
Parameter 4-10 Motor Speed Direction
Parameter 5-10 Terminal 18 Digital Input
Parameter 5-11 Terminal 19 Digital Input
Parameter 5-40 Function Relay
Parameter 8-03 Control Word Timeout Time
Parameter 8-04 Control Word Timeout Function
Parameter 8-10 Control Word Profile
Parameter 8-50 Coasting Select
Parameter 8-51 Quick Stop Select
Parameter 8-52 DC Brake Select
Parameter 8-53 Start Select
Parameter 8-54 Reversing Select
Parameter 8-55 Set-up Select
Parameter 8-56 Preset Reference Select
Parameter 9-16 PCD Read Configuration
Parameter 9-18 Node Address
Table 7.2 Parameter Settings

7.2 Example 2: Control Word Telegram using PPO Type

This example shows how the control word telegram relates to the PLC and the frequency converter, using FC control profile.
The PLC sends the control word telegram to the frequency converter. In the example, PPO Type 3 demonstrates the full
range of modules. All the values shown are arbitrary and are provided for demonstration purposes only.
Table 7.3 indicates the bits contained within the control word, and how they are presented as process data in PPO type 3 for
this example.
PCA IND
PQW 256 258
Bit 15 14 13
number
0 0 0
0
Table 7.3 Example: Control Word Telegram using PPO Type
MG37G202
Programming Guide
PCV
PVA
260 262
master slave
12 11 10 9 8
0 0 1 0 0
4
Danfoss A/S © 01/2016 All rights reserved.
Setting
[2] Both directions
[0] No operation
[10] Reversing
[36/37] Control word bit 11/12
1 s
[2] Stop
[0] FC Profile
[1] Bus
[1] Bus
[1] Bus
[1] Bus
[2] Logic AND
[1] Bus
[1] Bus
[2] Sub index parameter 16-16 Torque [Nm]
[3] Sub index parameter 16-60 Digital Input
Set the address
PCD
1 2
CTW MRV
04 7C 20 00
264 266 268
CTW MRV
7 6 5 4 3
0 1 1 1 1
7
3 4 5 6
PCD PCD PCD PCD
270 272 274
2 1 0
1 0 0
C
7 7
