Danfoss VLT PROFIBUS DP MCA 101 Programming Manual page 45

Parameters
9-44 Fault Message Counter
Range: Function:
0 [0 - Indicates the number of fault events presently
*
65535 ] stored in parameter 9-45 Fault Code. The buffer
capacity is maximum 8 error events. The buffer
and counter are set to 0 by reset or power-up.
9-45 Fault Code
Range: Function:
0 [0 - 0 ] This buffer contains the alarm word for all alarms
*
and warnings that have occurred since last reset or
power-up. The buffer capacity is maximum 8 error
events.
9-47 Fault Number
Range: Function:
0 [0 - 0 ] This buffer contains the alarm word for all alarms
*
and warnings that have occurred since last reset or
power-up. The buffer capacity is maximum 8 error
events.
9-52 Fault Situation Counter
Range: Function:
0 [0 - 1000 ] Indicates the number of fault events that have
*
occurred since last reset or power-up.
9-53 Profibus Warning Word
Read only
Range: Function:
0 [0 - 65535 ] This parameter shows PROFIBUS communi-
*
cation warnings. Refer to the VLT
MCA 101 Installation Guide for further
information.
Bit Description
0 Connection with DP-master is not OK.
1 Not used.
2 FDL (fieldbus data link layer) is not OK.
3 Clear data command received.
4 Actual value is not updated.
5 Baud rate search.
6 PROFIBUS ASIC is not transmitting.
7 Initialization of PROFIBUS is not OK.
8 Frequency converter is tripped.
9 Internal CAN error.
10 Wrong configuration data from PLC.
11 Wrong ID sent by PLC.
12 Internal fault occurred.
13 Not configured.
14 Timeout active.
15 Warning 34, Fieldbus fault active.
Table 6.1 PROFIBUS Warning Word
MG37G202
Programming Guide
9-63 Actual Baud Rate
Option:
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
[9]
[10]
[11]
[255]
*
9-64 Device Identification
Range:
0 [0 - 0] This parameter shows the device identification.
*
9-65 Profile Number
Range:
0 [0 - 0 ] This parameter contains the profile identification.
*
®
PROFIBUS DP
9-70 Programming Set-up
This parameter is unique for LCP and fieldbus. See
parameter 0-11 Programming Set-up.
Option:
[0] Factory setup Uses default data. This option can be used
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-up Follows the active set-up selected in
*
Danfoss A/S © 01/2016 All rights reserved.
Function:
This parameter shows the actual
PROFIBUS baud rate. The PROFIBUS
master automatically sets the baud
rate.
9,6 kbit/s
19,2 kbit/s
93,75 kbit/s
187,5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31,25 kbit/s
45,45 kbit/s
No baudrate found
Function:
®
Refer to the VLT PROFIBUS DP MCA 101 Installation
Guide for further explanation.
Function:
Byte 1 contains the profile number and byte 2 the
version number of the profile.
Function:
Select the set-up to edit.
as a data source to return the other set-ups
to a known state.
Edits set-up 1.
Edits set-up 2.
Edits set-up 3.
Edits set-up 4.
parameter 0-10 Active Set-up.
6 6
