Danfoss VLT PROFIBUS DP MCA 101 Programming Manual page 40

Parameters
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
6 6
[2] Logic
AND
[3] Logic OR Activates a start command via the fieldbus/serial
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates the reverse command via the fieldbus/
[3] Logic OR
38
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only selection
[0] Digital input is available.
Activates a start command via a digital input.
Activates a start command via the serial communi-
cation port or fieldbus option.
Activates a start command via the fieldbus/serial
communication port, and also via 1 of the digital
inputs.
communication port, or via 1 of the digital inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates a start command via a digital input.
Activates a start command via the serial
communication port or fieldbus option.
Activates a start command via the fieldbus/
serial communication port and also via 1 of the
digital inputs.
Activates a start command via the fieldbus/
serial communication port or via 1 of the digital
inputs.
Function:
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the fieldbus.
Activates the reverse command via the serial
communication port or fieldbus option.
serial communication port and also via 1 of the
digital inputs.
Activates the reverse command via the fieldbus/
serial communication port or via 1 of the digital
inputs.
Danfoss A/S © 01/2016 All rights reserved.
®
VLT PROFIBUS DP MCA 101
8-55 Set-up Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
8-56 Preset Reference Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates preset reference selection via the
[3] Logic OR
*
8-90 Bus Jog 1 Speed
Range:
100 RPM
8-91 Bus Jog 2 Speed
Range:
200 RPM
Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
Activates the set-up selection via a digital input.
Activates the set-up selection via the serial
communication port or fieldbus option.
Activates the set-up selection via the fieldbus/
serial communication port and via 1 of the
digital inputs.
Activates the set-up selection via the fieldbus/
serial communication port or via 1 of the digital
inputs.
Function:
Select control of the preset reference selection
via the terminals (digital input) and/or via the
fieldbus.
Activates preset reference selection via a digital
input.
Activates preset reference selection via the
serial communication port or fieldbus option.
fieldbus/serial communication port and via 1 of
the digital inputs.
Activates the preset reference selection via the
fieldbus/serial communication port or via 1 of
the digital inputs.
Function:
[ 0 - par. 4-13 Enter the jog speed. Activate this
*
RPM] fixed jog speed via the serial port
or fieldbus option.
Function:
[ 0 - par. 4-13 Enter the jog speed. Activate this
*
RPM] fixed jog speed via the serial port
or fieldbus option.
MG37G202
