Parameters
9-23 Parameters for Signals
Array [1000]
Read only
Option:
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1687] Bus Readout Alarm/Warning
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
6 6
[1693] Warning Word 2
[1694] Ext. Status Word
[1836] Analog Input X48/2 [mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1843] Analog Out X49/7
[1844] Analog Out X49/9
[1845] Analog Out X49/11
[1860] Digital Input 2
[3310] Sync Factor Master
[3311] Sync Factor Slave
[3401] PCD 1 Write to MCO
[3402] PCD 2 Write to MCO
[3403] PCD 3 Write to MCO
[3404] PCD 4 Write to MCO
[3405] PCD 5 Write to MCO
[3406] PCD 6 Write to MCO
[3407] PCD 7 Write to MCO
[3408] PCD 8 Write to MCO
[3409] PCD 9 Write to MCO
[3410] PCD 10 Write to MCO
[3421] PCD 1 Read from MCO
[3422] PCD 2 Read from MCO
[3423] PCD 3 Read from MCO
[3424] PCD 4 Read from MCO
[3425] PCD 5 Read from MCO
[3426] PCD 6 Read from MCO
[3427] PCD 7 Read from MCO
[3428] PCD 8 Read from MCO
[3429] PCD 9 Read from MCO
[3430] PCD 10 Read from MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
42
®
VLT PROFIBUS DP MCA 101
9-23 Parameters for Signals
Array [1000]
Read only
Function: Option:
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master Velocity
[3460] Synchronizing Status
[3461] Axis Status
[3462] Program Status
[3464] MCO 302 Status
[3465] MCO 302 Control
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
[3644] Terminal X49/7 Bus Control
[3654] Terminal X49/9 Bus Control
[3664] Terminal X49/11 Bus Control
[4280] Safe Option Status
[4282] Safe Control Word
[4283] Safe Status Word
[4285] Active Safe Func.
[4287] Time Until Manual Test
9-27 Parameter Edit
Option:
[0]
[1]
*
9-28 Process Control
Option:
[0]
[1]
*
Danfoss A/S © 01/2016 All rights reserved.
Function:
Edit parameters via:
•
PROFIBUS.
•
The standard RS485 interface.
•
The LCP.
Disabled Disables editing via PROFIBUS.
Enabled Enables editing via PROFIBUS.
Function:
Process control (setting of control word, speed
reference, and process data) is possible via either
PROFIBUS or standard fieldbus, but not both
simultaneously. Local control is always possible via
the LCP. Control via process control is possible via
either terminals or fieldbus depending on the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
Disable Disables process control via PROFIBUS master
class 1 and enables process control via standard
fieldbus or PROFIBUS master class 2.
Enable Enables process control via PROFIBUS master class
cyclic 1 and disables process control via standard
master fieldbus or PROFIBUS master class 2.
Function:
