Parameters
8-04 Control Word Timeout Function
Select the timeout function. The timeout function activates when
the control word fails to be updated within the time period
specified in parameter 8-03 Control Word Timeout Time.
Option: Function:
[7] Select Changes the set-up after a control word
setup 1 timeout. If communication resumes after a
timeout, parameter 8-05 End-of-Timeout
Function either resumes the set-up used before
the timeout, or retains the set-up endorsed by
the timeout function.
[8] Select See [7] Select set-up 1.
setup 2
[9] Select See [7] Select set-up 1.
setup 3
[10] Select See [7] Select set-up 1.
setup 4
[26] Trip
8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control
word following a timeout.
This parameter is active only when
parameter 8-04 Control Timeout Function is set
to:
•
[7] Set-up 1.
•
[8] Set-up 2.
•
[9] Set-up 3.
•
[10] Set-up 4.
[0] Hold set- Retains the set-up selected in
up parameter 8-04 Control Timeout Function and
shows a warning until parameter 8-06 Reset
Control Timeout toggles. Then the frequency
converter resumes its original set-up.
[1] Resume Resumes the set-up that was active before the
*
set-up timeout.
8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option: Function:
[0] Do not reset Retains the set-up specified in
*
parameter 8-04 Control Word Timeout Function,
following a control word timeout.
[1] Do reset Restores the frequency converter to the
original set-up following a control word
timeout. The frequency converter performs
the reset and then immediately reverts to the
[0] Do not reset setting.
MG37G202
Programming Guide
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on
alarms
[2] Trigger
alarm/warn.
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A are visible in the LCP display.
For guidelines in selection of [0] Frequency converter profile and
[1] PROFIdrive profile, refer to the design guide of the related
product.
For more guidelines in the selection of [1] PROFIdrive profile, [5]
ODVA, and [7] CANopen DSP 402, see the installation guide for the
installed fieldbus.
Option:
[0]
*
[1]
[5]
[7]
[8]
8-50 Coasting Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates start command via the fieldbus/serial
[3] Logic OR
*
8-51 Quick Stop Select
Select control of the quick stop function via the terminals (digital
input) and/or via the bus.
Option:
[0]
[1]
[2]
[3]
*
Danfoss A/S © 01/2016 All rights reserved.
Function:
Enables and controls the frequency converter
diagnosis function.
Extended diagnosis data is not sent even if
the data appears in the frequency converter.
Extended diagnosis data is sent when 1 or
more alarms appear.
Extended diagnosis data is sent if 1 or more
alarms/warnings appear.
Function:
FC profile
PROFIdrive profile
ODVA
CANopen DSP 402
MCO
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
Activates start command via a digital input.
Activates start command via the serial
communication port or fieldbus option.
communication port and 1 extra digital input.
Activates start command via the fieldbus/serial
communication port or via 1 of the digital
inputs.
Function:
Digital input
Bus
Logic AND
Logic OR
