System Operation
6. All run history log data are automatically stored in
internal Flash Memory as well as a USB Key, if one is
inserted.
Figure 16: Delivery Screen — Shutdown
7. Press the color-filled DONE button to return to the
opening screen.
Start and Stop Date
Start and Stop Time
Experiment
Transfectent
Electrode ID
Process Completion Type
Set Pulse Parameters
Average monitor pulse voltage
Average monitor pulse current
Average monitor pulse resistance
All monitor pulse voltage samples
All monitor pulse current samples
Monitor width of each pulse
Monitor interval of each pulse
Pre-pulse Load Reading
System Serial Numbers
System Software Versions
11
Raw Data
(CCEP <Date> <Time>.xml)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
AgilePulse ID In Vivo Gene Delivery System
Publication 015-101444 Rev 2.0 • www.btxonline.com

Experiment Delivery Logs

All collected data from the therapeutic/vaccine delivery are
automatically stored in the internal Flash Memory and an inserted
USB key under a unique chronological directory structure.
Included items are an XML file containing raw detailed system and
runtime data, a text log with basic runtime data, and a comma-
separated CSV file containing pulse monitor data. The directory
structure is constructed in a "AgilePulse\Log\<Year>\<Month>\<D
ay>\<Time>" hierarchy. A maximum of 20,000 delivery logs can be
stored in the internal system memory.
Text Log
(CCEP <Date> <Time>.log)
•
•
•
•
•
•
•
•
•
•
•
•
•
CSV Data
(CCEP <Date> <Time>.csv)
•
•
•
•
•
•
•
•
