- Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL ADU-22 DENTAL CART SYSTEM...
- Page 2 Setting Up the Unit ....2 P.O. Box 1548, Woodinville, WA 98072 - Fig. 1 - ADU-22 Cart System ..2 8333 216 treet S.E.
- Page 3 The compact and economical ADU-22 cart system is an ideal solution as an extra delivery cart or as a backup system. High and low-speed connections accept existing, air-driven handpieces. Casters allow smooth mobility between operatories. An air source is required for operation.
- Page 4 SETTING UP THE SYSTEM: 1. Place the ADU-22 Cart in an upright 3. The ADU-22 unit must be connected to a position on a flat, stable surface. Loosen dry, filtered, 60-90 psi air source. Simply the center column retaining knob and extend the 1/4"...
- Page 5 4. Remove the AA-21 high volume vacuum 6. To install water supply bottle, thread it into (HVE) system and High-Density the white plastic fitting at the left rear Polyethylene (HDPE) water supply tank from corner of the chassis (Fig. 4). packing and install on proper quick disconnects on the console (Fig.
- Page 6 1. THREE-WAY AIR/WATER SYRINGE - 2. HANDPIECE SELECTOR (Fig. 6) - The Depress the right button for air operation, Aseptico ADU-22 includes a handpiece and the left button for water operation. selector toggle on the front of the console Depressing both buttons will create a mist.
- Page 7 4. WATER ON/OFF TOGGLE (Fig. 8) - Controls the on/off flow of water coolant to the highspeed (HP1) handpiece. 5. WATER SUPPLY TANK - The Aseptico ADU-22 incorporates a self contained pressurized water system (Fig. 9). This TURN WATER SUPPLY...
- Page 8 OPERATION FUNCTIONS Cont’d 6. PRESSURE GAUGE (Fig. 8) - The QUICK pressure gauge on the front of the control DISCONNECT console gives you a visual indication of the drive air pressure to the handpiece in use. VACUUM ON/OFF 7. WATER COOLANT FLOW CONTROL (Fig.
- Page 9 SYSTEM ADJUSTMENTS: 1. HANDPIECE PRESSURE ADJUSTMENT (Fig. 11) - The amount of air pressure supplied to each handpiece may be adjusted by turning the flow-control screw for that handpiece. The control screws are located underneath the console, next to the HP1 and HP2 handpiece holders. Figure 11- Handpiece Pressure Controls HIGHSPEED HANDPIECE...
- Page 10 Because of its simple design, the Aseptico 4. PACKING THE UNIT FOR ADU-22 Cart requires very little TRANSPORTATION - If the ADU-22 unit is maintenance. Any maintenance that is going to be transported, it is recommended needed can be performed in minutes.
- Page 11 NOTES...
- Page 12 Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
