Aseptico ADU-17A2 Express Air 2 Operation And Maintenance Instruction Manual

Portable dental system
Hide thumbs Also See for ADU-17A2 Express Air 2:

Advertisement

OPERATION and MAINTENANCE
INSTRUCTION MANUAL
ADU-17A2 Express Air 2 Portable Dental System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADU-17A2 Express Air 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aseptico ADU-17A2 Express Air 2

  • Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL ADU-17A2 Express Air 2 Portable Dental System...
  • Page 2: Table Of Contents

    Street S.E. • Woodinville, WA 98072 Figures 2a thru 2e - Changing Voltage . .4 International (425) 487-3157 • Toll Free(800) 426-5913 www.aseptico.com • info@aseptico.com Figure 3 - Installing Instrument Holder . . .5 Figure 4 - Waste Tank Connections ..5 Figure 5 - Saliva Ejector Connection .
  • Page 3: Introduction

    Your new Aseptico Express Air 2 Portable Dental System is the finest portable electric dental sys- tem available. The ADU-17A2 features two handpiece controls, a 3-way air/water syringe, HVE and saliva ejector vacuum systems, a self contained water system, oilless air compressor, and vacuum pump.
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS: Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use, arising in particular through the non-observance of the operating instructions, or improper preparation and maintenance. WARNING: Sterilize before first and all uses. Clean, disinfect, and sterilize new or repaired instru- ments before first use.
  • Page 5: Setting Up The Unit

    SETTING UP THE UNIT: FIG. 1 - ADU-17A2 Express Air 2 LOW VOLUME VACUUM (SALIVA EJECTOR) 3-WAY AIR/WATER SYRINGE CLIP-ON INSTRUMENT HOLDER HANDPIECES (2) HIGH VOLUME VACUUM (HVE) WASTE CASE HANDLE TANK TIE-DOWN RESERVOIR CONNECTOR WATER SUP- HANDPIECE PLY BOTTLE HIGH / LOW...
  • Page 6 SETTING UP THE UNIT Cont’d 1. Unpack the ADU-17A2 Case. 2. Verify that the Voltage Selector Insert is config- Fig. 2b Fig. 2a ured properly by checking the voltage indicator on the Voltage Selector Module (Figure 2a). The Voltage Module is located on the lower left of the Motor Cover.
  • Page 7 3. Mount the clip-on Holder to the extended handle of connection. Connect the High Volume Vacuum the Case, as shown in Figure 3. (HVE) hose to the large gray connector located on the front of the Waste Tank. Connect the Low Fig.
  • Page 8: Operation Functions

    OPERATION FUNCTIONS: 1. ON/OFF SWITCH: c.) Unscrew and remove Bottle from cap. Turns the ADU-17A 2 system On or Off. d.) Fill Bottle with clean water. 2. AIR FOOT CONTROL: e.) Screw Bottle into the Water Reservoir The handpiece only operates when the foot Connector.
  • Page 9: Operation

    OPERATION: After the unit has been set up and you have FIG. 6 - HANDPIECE CONTROLS - LH made yourself familiar with the system functions, there are two operating modes to select from: HANDPIECE HIGH / LOW • On/Off Switch Operation - Switch ‘ON’ SWITCH activates the vacuum and 3-way air/water COOLANT...
  • Page 10: Sterilization & Maintenance

    STERILIZATION AND MAINTENANCE: Because of its simple design, the Aseptico ADU-17A2 Express Air 2 requires very little maintenance. Any maintenance that is needed can be performed in minutes. BLEEDING THE SYSTEM If the unit will not be used for an extended period of time, or the unit might be subjected to freezing conditions, you should bleed the system.
  • Page 11: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Unit will not start Check system’s power connection. Turn On/Off switch ON for operation. Check that voltage selector module is set for source voltage. Check fuse. If blown, replace with 6A/125V medium time delay fuse for 120V opera- tion, or a 4A/250V slo-blo fuse for 230V operation.
  • Page 12: Repacking Instructions

    REPACKING INSTRUCTIONS: 1. Remove all accessories from the unit. FIG. 10 2. Remove water bottle and place in travel pouch provided. 3. Position syringe in its holder on left side of case (Fig. 10). Lay tube behind syringe, next to waste tank. 4.
  • Page 13: Symbol Definitions

    SYMBOL DEFINITIONS: Type B Equipment Protective earth (ground) IPX1 Warning—Potential danger to Protect Against Dripping Water patient or user (consult accom- panying documents) Serial Number Dangerous Voltage Foot Switch Alternating current On/Off Switch Handpiece - Air Adjustment Switches Coolant Cavitron Connector This symbol indicates that the waste of electrical and electronic Fuses...
  • Page 14: Specifications

    SPECIFICATIONS: Size: 10.5” x 14.5” x 24” (27 cm x 36 cm x 61 cm) 1.81 cu. ft. (0.05 m 3) Volume: Weight: 43.5 lbs (19.7 kg) Power Source: AC Dual Voltage Manual-Switching 120V / 230V at 50Hz / 60Hz Current Rating: 6A at 120 VAC, or 4A at 230 VAC...
  • Page 15: Warranty

    In the event of alleged defect under warranty, the purchaser is to notify Aseptico's Customer Service Department promptly. Customer Service will provide instructions, usually directing that the product be returned for service. Shipment to Aseptico and the cost thereof is always the responsibility of the purchaser.
  • Page 16: P.o. Box 1548 • Woodinville, Wa

    P/N: 420967 P.O. Box 1548 • Woodinville, WA 98072 Rev. F 8333 216th Street SE • Woodinville, WA 98072 ECO 14117 (425) 487-3157 • (800) 426-5913 PRINTED IN 03/2017 www.aseptico.com • info@aseptico.com THE U.S.A.

Table of Contents
