  • Page 1 OPERATOR’S  MANUAL Model 220 Batch Freezers Original Operating Instructions 5/99 (Original Publication) 028763-M (Updated 6/5/2019)
  • Page 2 Note: Only instructions originating from the factory or its authorized translation representative(s) are considered to be the original set of instructions. © 1999 Taylor Company 028763-M Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this work may be...
  • Page 3: Table Of Contents

    Table of Contents Section 1: To the Installer Installer Safety ............1-1 Site Preparation .
  • Page 4 Table of Contents Section 8: Troubleshooting Guide Section 9: Parts Replacement Schedule Section 10: Limited Warranty on Equipment Section 11: Limited Warranty on Parts 028763-M...
  • Page 5: Section 1: To The Installer

    Taylor distributor. This machine is made using USA sizes of hardware. All Note: All repairs must be performed by a Taylor service metric conversions are approximate and vary in size. technician. To the Installer...
  • Page 6: Air-Cooled Machines

    This code contains GFI, installed by authorized personnel to local provisions considered necessary for safety. codes.  In all other areas of the world, the machine should be • Supply cords used with this machine shall be To the Installer Model 220...
  • Page 7: Refrigerant

    If the supply cord is damaged, it must be replaced by a Taylor service technician to avoid a hazard. WARNING! Refrigerant liquid sprayed onto the Beater Rotation skin may cause serious damage to tissue. Keep eyes and skin protected.
  • Page 8 TO THE INSTALLER Notes: To the Installer Model 220...
  • Page 9: Section 2: To The Operator

    If you require technical assistance, please contact your local authorized Taylor distributor. Note: Your Taylor warranty is valid only if the parts are authorized Taylor parts, purchased from the local authorized Taylor distributor, and only if all required service work is provided by a Taylor service technician.
  • Page 10: Compressor Warranty Disclaimer

    TO THE OPERATOR Compressor Warranty Disclaimer It should also be noted that Taylor does not warrant the refrigerant used in its equipment. For example, if the The refrigeration compressor(s) on this machine are refrigerant is lost during the course of ordinary service to...
  • Page 11: Section 3: Safety

    Safety Section 3 We at Taylor Company are concerned about the safety of operators at all times when they are coming in contact WARNING! Avoid injury. with the machine and its parts. Taylor makes every effort • DO NOT operate the machine unless it is to design and manufacture built-in safety features to properly grounded.
  • Page 12 It is recommended to place the contact. rear of the machine against the wall to prevent the recirculation of warm air. Failure to follow this instruction may cause poor freezer performance and damage to the machine. Safety Model 220...
  • Page 13 Noise Level: Airborne noise emission does not exceed 78 dB(A) when measured at a distance of 39 in. (1.0 m) from the surface of the machine and at a height of 62 in. (1.6 m) from the floor. Safety Model 220...
  • Page 14 SAFETY Notes: Safety Model 220...
  • Page 15: Operator Parts Identification

    Item Description Part No. Item Description Part No. Pan- Drip 027503 Shelf- Drip Tray 031753 Cover A.- Hopper- 110- 220 X24778- SER Panel- Front Lower 049441 Gasket- Hopper Cover 011412 Collar- Holding 019481 Panel- Rear 031749 Fastener- Clip 1/4- 20 U 045865 Funnel A.- Mix...
  • Page 16: Beater Door Assembly

    O-ring-2-1/8 OD x .139W-#225 020051 Beater A. X32269 Piston-Valve 030083 Blade-Scraper 052586 Pin-Hinge X04329 Shaft-Beater 032276 Pin A.-Pivot X34737 Seal-Drive Shaft 031316 Door A.-Partial Spout X32938 Screw A.-Cross Bar X07233 Cap A.-Cover X29667 Bar-Cross 011740 Operator Parts Identification Model 220...
  • Page 17: Accessories

    Pail- Mix 10 Quarts 013163 Brush- Rear BRG 1 X 2 X 14 013071 Lubricant- Taylor 047518 Brush- Draw Valve 1- 1/2 X 3 014753 Brush- Mix Tank Body 3”x7” 023316 Plunger A. X09585 Funnel- Plastic Door 065693 Operator Parts Identification Model 220...
  • Page 18 OPERATOR PARTS IDENTIFICATION Notes: Operator Parts Identification Model 220...
  • Page 19: Section 5: User Interface

    Turning the adjusting knob clockwise will decrease words on many of our operator switches and buttons product temperature. Turning the adjusting knob have symbols to indicate their functions. Your Taylor counterclockwise will increase product temperature. machine is designed with these international symbols.
  • Page 20 USER INTERFACE Notes: User Interface Model 220...
  • Page 21: Section 6: Operating Procedures

    Make sure the driveshaft fits into the mix hopper. coupling without binding. The Model 220 will produce 20 qt. (18.9 L) of frozen 20002 product from 10 qt. (9.5 L) of fresh mix. We begin our instructions at the point where we find the parts disassembled and laid out to air-dry from the previous brush-cleaning.
  • Page 22 20005 Figure 6-7 Slide the O-ring into the groove on the bearing holder, then lubricate. 20008 Figure 6-5 Insert the front bearing into the center hole on the back of the freezer door. Figure 6-8 Operating Procedures Model 220...
  • Page 23 Lightly lubricate the inside of the valve body in the Turn the bearing holder so the holes are aligned with freezer door. the holes in the valve body. Secure with the keeper pin. 20011 20014 Figure 6-11 Figure 6-14 Operating Procedures Model 220...
  • Page 24 20018 Figure 6-16 5. Align the holes in the cover cap assembly with the holes on the freezer door. Secure with the keeper pin. Figure 6-19 Operating Procedures Model 220...
  • Page 25: Sanitizing

    2. Install the O-ring on the bottom of the funnel. 20020 Figure 6-23 20023 Figure 6-21 3. Lay the funnel and the hopper gasket in the bottom of the mix hopper and pour the sanitizing solution into the hopper. Figure 6-24 Operating Procedures Model 220...
  • Page 26: Priming

    3. With the control switch in the OFF position, hold an 7. Assemble the hopper gasket around the top edge of empty pail beneath the ejection port. Turn the  the mix hopper. draw-rod handle and pull forward, opening the ejection port. Operating Procedures Model 220...
  • Page 27 This light is a visual signal that the product is down to its proper temperature. Place the control 20032 switch in the OFF position. Figure 6-31 Operating Procedures Model 220...
  • Page 28: Overrun

    Figure 6-37 If the plunger will not be used, fruits and nuts can be added through the freezer door without installing the plastic door funnel. Operating Procedures Model 220...
  • Page 29: Drawing Product

    3. Put the control switch into the EJECT position and allow the water to agitate for approximately 1 minute. Operating Procedures Model 220...
  • Page 30: Cleaning/Sanitizing

    Place all the cleaned parts on a Also remove the adjustable shelf. Take these parts to clean, dry surface to air-dry overnight. the sink for further disassembly and cleaning. 6-10 Operating Procedures Model 220...
  • Page 31 5. Return to the freezer with a small amount of cleaning 6. Wipe clean the shelf and all exterior surfaces of the solution. With the black bristle brush, brush-clean the freezer. rear shell bearing at the back of the freezing cylinder. 20030 Figure 6-41 6-11 Operating Procedures Model 220...
  • Page 32 OPERATING PROCEDURES Notes: 6-12 Operating Procedures Model 220...
  • Page 33: Section 7: Operator's Checklist

    Deteriorated or cracked water lines Properly prepare the cleaning/sanitizing solution.  should be replaced only by a Taylor service Read and follow the label directions carefully. Too technician. strong of a solution may damage the parts, and too weak of a solution will not do an adequate job of cleaning and sanitizing.
  • Page 34: Winter Storage

    This is extremely important. Failure to follow this procedure may cause severe and costly damage to the refrigeration system. Your local Taylor distributor can perform this service for you. Wrap detachable parts of the freezer (such as the beater, blades, driveshaft, and freezer door) and place these parts in a dry, protected place.
  • Page 35: Troubleshooting Guide

    Lubricate properly. seal. c. Rear shell bearing is worn. c. Contact a service technician. d. The wrong type of lubricant is d. Use Taylor Lube. being used. 6. Buzzer does not sound a. Buzzer is malfunctioning. a. Contact a service technician.
  • Page 36 After drawing out the first portion, after drawing some product out to place the control switch in the OFF place in the hardening cabinet. position. Return to freezer to draw out more product; place control switch in the EJECT position. Troubleshooting Guide Model 220...
  • Page 37: Parts Replacement Schedule

    Black Bristle Brush, 1” x 2” Inspect and Minimum replace if necessary. White Bristle Brush, 1- 1/2” x 2” Inspect and Minimum replace if necessary. White Bristle Brush, 3” x 7” Inspect and Minimum replace if necessary. Parts Replacement Schedule Model 220...
  • Page 38 PARTS REPLACEMENT SCHEDULE Notes: Parts Replacement Schedule Model 220...
  • Page 39: Limited Warranty On Equipment

    LIMITED WARRANTY Taylor warrants the Product against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original Product installation. If a part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or ...
  • Page 40 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
  • Page 41: Limited Warranty On Parts

    Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or remanufactured Part, at Taylor’s option, to replace the failed defective Part at no charge for the Part.
  • Page 42 Taylor. 5. Replacement of wear items designated as Class “000” Parts in the Taylor Operator’s Manual, as well as any release sheets and clips for the Product’s upper platen assembly.
  • Page 43 LEGAL REMEDIES The owner must notify Taylor in writing by certified or registered letter to the following address of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
  • Page 44 LIMITED WARRANTY ON PARTS Notes: 11-4 Limited Warranty on Parts Model 220...
