Viewing the position of the pick-ups

During work, the pick-up position can be viewed on the
screen.
- Shortly press navigation key.
• Symbols (1) and (2) indicate that the pick-ups are in
lower position.
• The symbol (3) indicates the pick-up is in raised
position.
When symbol (2) is steady, the central pick-up
can be controlled.
When symbol (2) flashes, the central pick-up is
no longer controlled.
When the machine functions in deteriorated
mode, all pick-ups appear in low position.
Deteriorated mode: See section: Use in
deteriorated mode.
- Press shortly on the navigation key to quit viewing the
pick-up position and to return to the hour counter.
