For machines with hoppers or tanks:
- If the total unit weight exceeds the tractor Gross Combined Weight Rating in accordance
with the countrie's legislation, empty the hopper to travel on public roads.
- In any case, we recommend to travel on public roads with empty hoppers and tanks.

Description of symbols

Description Units
T
PTAC
T1
T2
t
t1
t2
t1 max
t2 max
M1
Stage 1:
To measure:
- Tractor tare (T).
10
Safety
kg Tractor unladen weight
kg Gross Combined Weight Rating
kg Unladen load on tractor front axle
kg Empty load on tractor rear axle
kg Axle loads (Tractor + machine)
kg Load on front axle (Tractor + machine)
kg Load on rear axle (Tractor + machine)
kg Maximum load authorized on the tractor front axle according to the tires
kg Maximum load authorized on the tractor rear axle according to the tires
kg Total weight of front tool or front ballast
