OPERATOR'S MANUAL
ZN115BGB B
Tedder-rake combination
Original instructions
ZN115BGB B
- English - 06-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAYBOB 300 and is the answer not in the manual?

Questions and answers

Related Manuals for KUHN HAYBOB 300

Summary of Contents for KUHN HAYBOB 300

  • Page 1 OPERATOR'S MANUAL ZN115BGB B Tedder-rake combination Original instructions ZN115BGB B - English - 06-2019...

  • Page 3: Dear Owner

    $Dear Owner You have purchased a KUHN machine. Into it have gone years of thought, research and improvement. You will find, as have thousands of owners all over the world, that you have the best that engineering skill and actual field testing can produce.

  • Page 4: Table Of Contents

    Tedder-rake combination HAYBOB 300 $Contents Dear Owner ........................1 Contents..........................2 Delivery ...........................6 Check on delivery..........................6 Identification of the machine..................7 Front view............................7 Rear view............................7 Model identification plate ........................8 Optional equipment........................10 Safety..........................11 Description of symbols used in this document................11 Safety instructions .........................12 Likely critical failures ........................20...
  • Page 5 Tedder-rake combination HAYBOB 300 Preparation for use ...................... 34 Safety .............................. 34 Check at beginning of the season ....................35 Road transport ......................36 Safety .............................. 36 Preparations in the field ........................ 38 Machine transport using transport means .................. 37 Preparations in the field ....................
  • Page 6 Tedder-rake combination HAYBOB 300 Maintenance........................47 Safety...............................47 Protection measures ........................49 General ............................50 Maintenance table ..........................53 Complete machine..........................54 Bolted connections ........................55 PTO drive shaft ..........................56 Cleaning ............................57 Cleaning ........................57 Cleaning ............................57 Parking and storage.....................58 Safety...............................58 Storage ............................58 Dismantling and scrapping of the machine .................59...
  • Page 7 Tedder-rake combination HAYBOB 300 Troubleshooting guide ....................60 General ............................60 Limited Warranty......................61 Appendix ........................63 Calculating the load on an axle..................... 63 Torque value ........................... 69 Disposal of the machine ........................ 73 PTO drive shaft ..........................74 Contents...

  • Page 8: Delivery

    Tedder-rake combination HAYBOB 300 $Delivery 1. Check on delivery The machine will arrive fully assembled. Check the machine after delivery for loose or missing parts. In case parts are not assembled please contact your dealer. In case parts are missing or the machine was damaged during transport, please immediately contact your dealer, importer, or the manufacturer.

  • Page 9: Identification Of The Machine

    Tedder-rake combination HAYBOB 300 $Identification of the machine 1. Front view 2. Rear view Identification of the machine...

  • Page 10: Model Identification Plate

    Please write below the type and serial number of the machine. This information is to be given to your KUHN dealer for all parts order or warranty claim. Type: Serial no.:...
  • Page 11 Tedder-rake combination HAYBOB 300 Model identification plate Manufacturer name and address Brand KUHN logo 3: Brand Description of the machine 9: Serial Nr. 34: Ex 5: Machine Model 7: Model Machine serial number 12: Unladen Mass min/Max Weight empty (minimum / maximum)

  • Page 12: Optional Equipment

    Tedder-rake combination HAYBOB 300 4. Optional equipment Tick box corresponding to the equipment fitted on your machine: Warning sign and light set Identification of the machine...

  • Page 13: Safety

    Tedder-rake combination HAYBOB 300 $Safety 1. Description of symbols used in this document This symbol indicates a potentially hazardous situation that if not avoided, could result in serious bodily injury. This symbol is used to identify special instructions or procedures which, if not followed strictly, could result in machinery damage.

  • Page 14: Safety Instructions

    Tedder-rake combination HAYBOB 300 2. Safety instructions Who is allowed to operate the machine? Only qualified personnel Only qualified personnel who have been informed about the dangers associated with handling the machine are permitted to operate, service or repair the machine. This knowledge can be gained by agricultural training, technical training or intensive instruction.
  • Page 15 Tedder-rake combination HAYBOB 300 Good working condition Ensure that the machine and your tractor are always in a proper operating condition. Always work with a clean machine, remove any dirt before operation. Observe the information and technical data in the operation manual of your tractor.
  • Page 16 Tedder-rake combination HAYBOB 300 Hitching the machine Increased risk of injury While hitching the machine to the tractor there is an increased danger of injury. Therefore always: • Secure the tractor and the machine from rolling away • Switch off all hydraulic systems.
  • Page 17 Tedder-rake combination HAYBOB 300 Tractor loads The load per axle can be: • Determined, as described below • Calculated, see appendix 1 Gross weight and weight per axle The drawings are not legally binding, their only aim is to illustrate the method to use.
  • Page 18 Tedder-rake combination HAYBOB 300 How to proceed: Stage 1: To measure: - Tractor tare(T). T = _____kg Stage 2: - Couple the machine to the tractor. To measure: - Load on front axle (t1): • Tractor + machine (transport position).
  • Page 19 Tedder-rake combination HAYBOB 300 Stage 3: To measure: - Total weight (t): • Tractor + machine (transport position). • Ballast weights. Checking: - To go to the next stage: • Check in the tractor's operator's manual that the value measured is below the tractor's Gross Combined Weight Rating.
  • Page 20 Tedder-rake combination HAYBOB 300 Hydraulics Hydraulic couplings only pressureless Only connect hydraulic hoses to the tractor hydraulic system if the tractor and machine's hydraulic system is pressureless. A pressurized hydraulic system can trigger unforeseen movements at the machine and may cause serious damage or fatal injury.
  • Page 21 Tedder-rake combination HAYBOB 300 Road transport Ensure road safety If you intend to transport the machine on public roads, the machine and the combination of tractor and machine have to comply to current Road Traffic Act's requirements. This to guarantee your own safety and the safety of other road users.

  • Page 22: Likely Critical Failures

    Tedder-rake combination HAYBOB 300 3. Likely critical failures • 133993: Specific requirements for countries member of the Eurasian Economic Community (EAC marking) • 133994: Specific requirements for countries member of the Eurasian Economic Community (EAC marking) • 133995: Specific requirements for countries member of the Eurasian Economic Community (EAC marking) 4.
  • Page 23 Tedder-rake combination HAYBOB 300 Operation First use only after instruction It is not allowed to operate the machine until distribution company employees, company representatives or manufacturer's employees have given instruction. If initial operation is performed without instruction, damage to the machine can be caused by operating errors and accidents can occur.
  • Page 24 Tedder-rake combination HAYBOB 300 Instructions in case of malfunctions In case of a malfunction, stop the machine immediately: • Switch off tractor hydraulics. • Switch off electrical systems. • Turn off tractor engine and. • Remove the ignition key. Perhaps the malfunction can be eliminated immediately, otherwise contact your dealer. Using a faulty machine can cause accidents or damage.
  • Page 25 Tedder-rake combination HAYBOB 300 Unhitching the machine Increased risk of injury An increased risk of injuries occurs when unhitching the machine from the tractor. Therefore: • Prevent the tractor and machine from rolling away • Switch off tractor hydraulics. • Switch off electronic systems.
  • Page 26 Tedder-rake combination HAYBOB 300 Maintenance Observe the care and maintenance instructions Observe the prescribed intervals for maintenance, checks and inspections specified in this manual. If maintenance, checks and inspections are not complied with, damage to the machine or accidents can occur.
  • Page 27 Tedder-rake combination HAYBOB 300 Maximum hydraulic oil pressure 210 bar (3045 psi) The prescribed maximum hydraulic oil pressure of 210 bar (3045 psi) may never be exceeded. A higher hydraulic oil pressure can damage the machine. Searching for hydraulic oil leaks Never search for leaks by touching hydraulic hoses and hydraulic connections, even when your hands are protected with a protective skin cream or oil-resistant gloves.

  • Page 28: Location And Description Of Safety Decals On The Machine

    Tedder-rake combination HAYBOB 300 6. Location and description of safety decals on the machine Location of safety decals The machine has safety decals for indicating attention to dangers. The labels may not be removed. Keep all safety decals clean and legible. In case safety decals are damaged, perished or lost, order new decals as spare parts and affix them on the machine.
  • Page 29 Tedder-rake combination HAYBOB 300 Description of safety decals Read the operation manual (Combined safety decal) The machine may only be commissioned once the operation manual has been read and fully understood. This applies in particular to the safety instructions. This is a hazardous situation which, if not avoided, could result in minor or major injuries.

  • Page 30: Machine Specifications

    Tedder-rake combination HAYBOB 300 $Machine specifications 1. General This chapter contains the following information: • Range of applications and properties. • Technical specifications. Product description This machine is only designed for the use of agricultural purposes. The machine is designed for raking and/or tedding grassy plants in agricultural environment only.

  • Page 31: Description And Glossary

    Tedder-rake combination HAYBOB 300 2. Description and glossary 3-point hitch Main frame Protection tube, left hand side Drive shaft Protection tube, right hand side Rotor Swath deflector Designated use of the machine This machine is only designed for the use of agricultural purposes. Any use whatsoever other than the above mentioned is improper use.

  • Page 32: Technical Specifications

    Tedder-rake combination HAYBOB 300 3. Technical specifications Machine specifications 3-Point linkage, category 1 - 2 Number of rotors Number of tines per rotor Working width spreading and tedding 3.00 m Working width - Single swath raking: 3.00 m (central delivery) - Double swath raking: 6.00 m (in 3 passes)

  • Page 33: Hitching The Machine

    Tedder-rake combination HAYBOB 300 4. Hitching the machine Safety Wear safety shoes During all work at the machine never bring your feet under the machine and always wear safety shoes. Wearing safety shoes prevents and decreases the risk of serious injuries.
  • Page 34 Tedder-rake combination HAYBOB 300 Preparing the tractor The tractor must be fitted with lower link stabilizers. for easier attachment and pitch angle adjustment, we recommend to use a hydraulic top link. In this case, an additional double acting outlet is required.
  • Page 35 Tedder-rake combination HAYBOB 300 Before hitching the machine: - Set the control lever of the 3-point hitch in a position that prevents from inadvertent actuation of any function - Hitch the machine to the tractor lower links and top link.

  • Page 36: Preparation For Use

    Tedder-rake combination HAYBOB 300 $Preparation for use 1. Safety Obey safety instructions Obey the safety instructions at the execution of all work. Any disregard for safety instructions can lead to serious or fatal injuries. - Safety instructions, see page 12.

  • Page 37: Check At Beginning Of The Season

    Tedder-rake combination HAYBOB 300 2. Check at beginning of the season - Run the tractor hydraulics at idle. - Run the machine at 350 rpm for some minutes. - Check the components for operating correctly. - Check for unusual noises - Switch off the tractor hydraulics.

  • Page 38: Road Transport

    Tedder-rake combination HAYBOB 300 $Road transport 1. Safety Before road transport will take place, please read the following safety instructions. The compliance is mandatory and helps you to avoid accidents. Observe safety instructions Observe the safety instructions for carrying out all kind of jobs. Any disregard for safety instructions may lead to serious or fatal injuries.

  • Page 39: Machine Transport Using Transport Means

    Tedder-rake combination HAYBOB 300 Carrying people and objects on the machine is prohibited Neither persons nor objects are allowed to be transported at the machine at any time. Only parts stored in their dedicated storage locations are alllowed to be transported at the machine. Riding on the machine is hazardous and strictly prohibited.

  • Page 40: Preparations In The Field

    Tedder-rake combination HAYBOB 300 $Preparations in the field 1. Safety Obey the safety instructions Obey the safety instructions at the execution of all work. Any disregard for safety instructions can lead to serious or deadly injuries. Safety instructions, see page 12.

  • Page 41: Operation

    Tedder-rake combination HAYBOB 300 $Operation 1. Safety Obey the safety instructions Observe the safety instructions for carrying out all kind of jobs. Any disregard for safety instructions may lead to serious or fatal injuries. Safety instructions, see page 12. Wear safety shoes During all jobs at the machine never bring your feet under the machine and always wear safety shoes, to decrease the risk of serious injuries.

  • Page 42: Start Position

    Tedder-rake combination HAYBOB 300 2. Start position Place the machine in the start position, the start position is reached when: • The tractor engine is running idle • The machine is in the operation position • The 3-point hitch is raised.
  • Page 43 Tedder-rake combination HAYBOB 300 3. General instructions for use For a good opertion of the machine the following have to be respected: • To enable the machine to follow ground contours correctly, the hydraulic lift lever should be in float position during work, so that the lift arms can move freely up and down.
  • Page 44 Tedder-rake combination HAYBOB 300 Adjustments for spreading and tedding - Lower machine and start a right hand turn. - Then pull cord (4) to disengage lever (2) from bracket pin (3). - Set all tines to tedding position (6). - Use the lower holes (7) for wheel height adjustment: to avoid strips being left between the rotors (e.g.
  • Page 45 Tedder-rake combination HAYBOB 300 To prevent the crop being moved too far to the side, especially when working around the boundary of the field, the tedding width of the machine can be restricted by the deflectors (5) which can be set laterally, using stays (8).
  • Page 46 Tedder-rake combination HAYBOB 300 4. Adjustment for raking - Lower machine and start a right hand turn. - Then pull cord (4) to disengage lever (2) from bracket pin (3). - Set all tines to raking position (9). - Use the upper holes (10) for wheel adjustment. In long stubbles the use of the lower holes can be advantageous for better pick-up and clean raking.
  • Page 47 Tedder-rake combination HAYBOB 300 When adjusting the top link ensure a safe distance to the tines of the rotating rotors is kept! - Set deflectors as required using stays (8). Always make certain that the distance between the deflectors is large enough, especially in a heavy crop to prevent material from being pulled out of the swath.

  • Page 48: Optional Equipment

    Tedder-rake combination HAYBOB 300 $Optional equipment 1. Warning sign and light set The use of warning shields is compulsory by law in some countries. - Use the warning shields in these countries. Optional equipment...

  • Page 49: Maintenance

    Tedder-rake combination HAYBOB 300 $Maintenance 1. Safety Before leaving the tractor or before adjusting, maintaining or repairing the machine, disengage the PTO drive, turn off the engine, remove ignition key and wait until all moving parts have come to a complete stop and apply park brake.
  • Page 50 Tedder-rake combination HAYBOB 300 Wear safety shoes During all jobs at the machine never bring your feet under the machine and always wear safety shoes, to decrease the risk of serious injuries. Conditions for maintenance jobs Only carry out maintenance jobs if you have the required expertise and the suitable tools. The absence of technical knowledge or unsuitable tools can cause accidents or damages.

  • Page 51: Protection Measures

    Tedder-rake combination HAYBOB 300 2. Protection measures Additives in oil and lubricants may have harmful effects to health. Be always aware of the safety instructions, warnings and cautions mentioned at the original package of the oil and lubricants. Because an indication according to the danger order is not necessary, therefore pay attention to the instructions below.

  • Page 52: General

    Tedder-rake combination HAYBOB 300 3. General At all maintenance tasks, secure the machine in the operating position. In case the transport position is required, this is mentioned separately. Directions Direction specifications (left, right, front, rear) are always meant in relation to direction of travel.
  • Page 53 Tedder-rake combination HAYBOB 300 4. General After a few hours of a new or overhauled machine check that all nuts and bolts are tight. Special attention should be paid to those holding the tines and bolts securing the rotors, located under the top of the rotors. Recheck regularly.
  • Page 54 Tedder-rake combination HAYBOB 300 5. Lubrication Warranty and damages Warranty claims of all damages caused by insufficient lubrication will be rejected. Always use a good and adhesive multi-purpose grease when lubricating the machine and PTO shaft. Machine - The top of each gearbox has a grease nipple, next to...

  • Page 55: Maintenance Table

    Tedder-rake combination HAYBOB 300 6. Maintenance table General Cleaning: - Complete machine - Lighting [+] Check: - Safety decals - Lighting [+] - PTO drive shaft - Cleaning Tighten: - Bolts and nuts - PTO drive shaft Lubrication Lubricate: - PTO drive shaft...

  • Page 56: Complete Machine

    Tedder-rake combination HAYBOB 300 Complete machine Cleaning Clean the machine always: • After operation. • At the start of each season • At the end of each season. • Before storage. Cleaning, see page 57. Parking and storage, see page 58.

  • Page 57: Bolted Connections

    Tedder-rake combination HAYBOB 300 8. Bolted connections Replace a missing or broken bolt or nut, always by a genuine part. Standard bolts and nuts may look the same, have different qualities properties. Non-genuine parts may change the properties of the machine, and may make the machine unsafe.

  • Page 58: Pto Drive Shaft

    Tedder-rake combination HAYBOB 300 9. PTO drive shaft Protective parts All protective parts of the PTO drive shaft have to be in a proper, undamaged condition. Replace defective parts. An unprotected PTO drive shaft or damaged protective parts can cause serious injuries.

  • Page 59: Cleaning

    Tedder-rake combination HAYBOB 300 $Cleaning 1. Cleaning After every use of the machine empty and clean the machine off all accumulated crop and dirt. Cleaning can be done with a high pressure cleaner. Avoid bearings, seals, hydraulic parts and bolted joints from water permeation.

  • Page 60: Parking And Storage

    Tedder-rake combination HAYBOB 300 $Parking and storage 1. Safety Obey the safety instructions Obey the safety instructions at the execution of all work. Any disregard for safety instructions can lead to serious or fatal injuries. Safety instructions, see page 12.

  • Page 61: Dismantling And Scrapping Of The Machine

    Tedder-rake combination HAYBOB 300 3. Dismantling and scrapping of the machine At the end of the machine's life, the various machine components must be disposed of or recycled in compliance with local regulations in force. - Make sure the machine is stable (parking stands, holders, slings, etc.) prior to carrying out any repair or maintenance - Before any repair or maintenance on a circuit including an accumulator, depressurize the circuit.

  • Page 62: Troubleshooting Guide

    Tedder-rake combination HAYBOB 300 $Troubleshooting guide 1. General Before start to resolve problems, always secure the machine and tractor from rolling away and unintentional operating. Always observe all safety instructions during maintenance and repair jobs. See also chapter maintenance. Safety, see page 11.

  • Page 63: Limited Warranty

    KUHN equipment from an authorized KUHN dealer, that such equipment is, at the time of delivery to such purchaser, free from defects in material and workmanship, and that such equipment is covered under this Limited Warranty providing the machine is used and serviced in accordance with the recommendations in the Operator's manual.
  • Page 64 - The warranty claim is completed on line via extranet - www.kuhn.com or submitted on a KUHN warranty claim form and returned to the Company within one month after the date of failure or the date of problem becoming apparent.

  • Page 65: Appendix

    Tedder-rake combination HAYBOB 300 $Appendix 1. Calculating the load on an axle When coupling a tool to the front and/or rear 3-point lift linkage, the maximum authorized payload must not be exceeded. The load on the tractor front axle must always represent 20 % of the tractor unladen weight.
  • Page 66 Tedder-rake combination HAYBOB 300 Rear tool or front-rear combination: 1) Calculation of the minimum front ballast weight M1 minimum M2 x (c+d) - T1 x b + 0.2 x T x b minimum Write the minimal additional weight in the chart.
  • Page 67 Tedder-rake combination HAYBOB 300 Table: Actual value obtained Value authorized Double value of the by calculation according to authorized capacity operator's manual per tyre (2 tyres) Minimum front/rear ballasting Total weight Load on front axle Load on rear axle The minimum ballasting must be made by fitting a tool or an additional mass to the tractor.
  • Page 68 Tedder-rake combination HAYBOB 300 Determining the machine weight (M2) and the position of its centre of gravity (d) If the data required to calculate the total weight, axle loads and minimum ballasting are not supplied, use the following method. Tractor only: - T1: Load on front axle.
  • Page 69 Tedder-rake combination HAYBOB 300 - T: Axle loads. • Tractor only. T = _____kg Appendix...
  • Page 70 Tedder-rake combination HAYBOB 300 Rear tool or front-rear combination: If the total unit weight exceeds the tractor Gross Combined Weight Rating in accordance with the countrie's legislation, empty the hopper to travel on public roads. In any case, we recommend to travel on public roads with empty hoppers and tanks.

  • Page 71: Torque Value

    Tedder-rake combination HAYBOB 300 2. Torque value All screwed joints on this machine must have a torque in accordance with the values given in the table below unless indicated otherwise. On this machine, 8.8 is both standard and minimum quality used. If not indicated otherwise use this quality for determination of torque (in most cases the quality can be found on the head of the respective bolt).
  • Page 72 Tedder-rake combination HAYBOB 300 Metric thread with standard pitch Thread Class Torque value Max. assembly preload Maxi (u =0.12) ft-lb (in-lb) 151.9 80900 10.9 222.7 118800 (X2) 12.9 139000 217.6 102000 10.9 310.5 145000 (X2.5) 12.9 170000 130000 10.9 436.6 186000 (X2.5)
  • Page 73 Tedder-rake combination HAYBOB 300 Metric thread with fine pitch Thread Class Torque value Max. assembly preload Maxi (u =0.12) ft-lb (in-lb) 26.1 19.2 20200 M8X1 10.9 38.3 28.2 29700 12.9 44.9 33.1 34700 37.6 31600 M10X1.25 10.9 55.3 46400 12.9 64.2...
  • Page 74 Tedder-rake combination HAYBOB 300 Metric thread with fine pitch Thread Class Torque value Max. assembly preload Maxi (u =0.12) ft-lb (in-lb) 209000 M24X2 10.9 1095 807.6 297000 12.9 1282 945.5 348000 The values listed apply to dry or slightly lubricated connections.

  • Page 75: Disposal Of The Machine

    Tedder-rake combination HAYBOB 300 3. Disposal of the machine At the end of the machine's lifetime, the individual components have to be disposed of in a correct environmentally friendly way. Please observe the current valid national waste disposal regulations. Metal parts All metal parts can be disposed of in the used metal recycling system.

  • Page 76: Pto Drive Shaft

    Tedder-rake combination HAYBOB 300 4. PTO drive shaft In some cases the length of the PTO drive shaft has to be adapted. The length of the PTO shaft depends on the distance between the tractor and machine. Protection tube Profiled tube Check length of the PTO drive shaft min.
  • Page 77 $Specimen of the "Declaration of conformity" EC Declaration of conformity (European directive 2006/42/CE) The manufacturer: Manufacturer name and address declares that the product described hereafter: Brand Brand Machine Machine Type / Model : Type / Model Serial no. Serial no. - conforms to the requirements of the European directive 2006/42/CE.
  • Page 78 KUHN S.A. - B.P. 50060 - F - 67706 SAVERNE CEDEX (FRANCE) KUHN-AUDUREAU SAS - B.P. 19 - F - 85260 LA COPECHAGNIERE (FRANCE) KUHN-BLANCHARD SAS - 24, route de Nantes - F - 44680 CHEMERE (FRANCE) KUHN-HUARD SAS - B.P. 49 - F - 44142 CHATEAUBRIANT CEDEX (FRANCE) KUHN-GELDROP B.V.
